Table 1-2 Product dimensions
Product Width Depth Height Weight
HP ScanJet Enterprise Flow N9120 fn2
Document Scanner (closed)
601.98 mm (23.7 in) 635 mm (25 in) 287.02 mm (11.3 in) 21.4 kg (47.18 lb)
HP ScanJet Enterprise Flow N9120 fn2
Document Scanner (open)
601.98 mm (23.7 in) 754.38 mm (29.7 in) 622.3 mm (24.5 in) 21.4 kg (47.18 lb)
Power consumption, electrical specifications and acoustic emissions
Power usage drops significantly while in Ready or Sleep mode, which saves natural resources and saves money
without affecting the high performance of this product.
AC power FB scan Duplex ADF scan
300 dpi 600 dpi 300 dpi 600 dpi
AC110V < 30 W < 30 W < 60 W < 50 W
AC230V < 30 W < 30 W < 60 W < 50 W
Power Sleep mode Off
AC110V < 2 W < 0.2 W
AC230V < 2 W < 0.2 W
Operating environment range (HP Digital Sender Flow 8500 fn2 Document Capture
Workstation)
This product is intended to be supplied by a Listed Power Unit, marked with LPS or Limited Power Source. The
power supply is rated 100–240V~, and has a DC output of 32 Vdc, 1.56 A, 50 W.
Name Description
Temperature Operating the scanner: 10° to 35° C (50° to 95° F)
Storage: -40° to 60° C (-40° to 140° F)
Relative humidity Operating the scanner: 15% to 80% non-condensing 10° to 35° C (50° to 95° F)
Storage: up to 90% at 30° to 60° C (86° to 149° F)
Operating environment range (HP ScanJet Enterprise Flow N9120 fn2 Document
Scanner)
This product is intended to be supplied by a Listed Power Unit, marked with LPS or Limited Power Source. The
power supply is rated 100–240V~, and has a DC output of 32 Vdc, 1.56 A, 50 W.
12 Chapter 1 Product overview ENWW
