HP Digital Sender Flow 8500 fn2 Document Capture Workstation - Manual (Page 65)

5. Select settings and complete tasks in Quick Sets Setup. Click Next to proceed to the next page of available
options until reaching the Summary page.
NOTE: The settings available in Quick Sets Setup vary by the type of Quick Set being copied. Refer to the
tables in Quick Set settings and options on page 55 to see the available settings and options for each
type of Quick Set.
6. Review the Summary page, and then click Finish to save the Quick Set.
Remove a Quick Set
Use the following steps to remove a Quick Set.
1. Using the top navigation tabs, click General.
2. In the left navigation pane, click Quick Sets.
3. In the Quick Sets List area, click the check box next to the appropriate Quick Set, and then click Remove.
4. When the Confirmation Page opens, click Remove to finish removing the Quick Set.
Quick Set settings and options
The following tables list the settings and options available in the Quick Set Wizard when adding, editing, or
copying a Quick Set.
Table 2-5 Address and Message Field Control — Scan to Email Quick Sets
Option Description
Address Field Restrictions Use the Address Field Restrictions drop-down list to specify whether users can type an email address
or select an email address from an address book
From: Use the From: drop-down list to set the email address that displays in the From: field of the email.
If Default From: is selected, the email address listed in the Default From: field is used.
If User's address (sign-in required) is selected, the user is required to sign in to the product with their
email address when using the Quick Set.
This field can be set to be user-editable.
Default From: The Default From: field is used to define the email address used when Default From: is selected in the
From: drop-down list.
Default Display Name: Use this field to set the name displayed on the product's control panel. If this field is not set, the value
in the Default From: displays on the product's control panel.
This field is optional.
To:
CC:
BCC:
Use these drop-down lists to set the email recipient, CC (carbon copy) and BCC (blind carbon copy)
values.
The options for each of these fields are:
● User's address (sign-in required)
● Blank
● Specify address
These fields can be set to be user-editable
ENWW Set up the scanner 55
