HP Digital Sender Flow 8500 fn2 Document Capture Workstation - Manual (Page 112)

Table 4-6 HP Embedded Web Server Security tab (continued)
Menu Description
Web Service Security Allow resources on this scanner to be accessed by web pages from different domains. If no
sites are added to the list, then all sites are trusted.
Self Test Verify that the security functions are running according to expected system parameters.
HP Web Services tab
Table 4-7 HP Embedded Web Server HP Web Services tab
Menu Description
Configuration
Web Proxy Configure a proxy server if there are issues enabling HP Web Services or connecting the
device to the internet.
Networking tab
Use the Networking tab to configure and secure network settings for the scanner when it is connected to an IP-
based network. This tab does not display if the scanner is connected to other types of networks.
Table 4-8 HP Embedded Web Server Networking tab
Menu Description
Configuration
TCP/IP Setting Configure TCP/IP settings for IPv4 and IPv6 networks.
Network Settings Configure IPX/SPX, AppleTalk, DLC/LLC, and SNMP settings.
Other Settings Includes firmware update, LPD queues, USB settings, support information, and refresh rate.
AirPrint Enable, set up, or disable network printing from Apple supported products.
Select Language Change the language displayed by the HP Embedded Web Server. This page displays if the
Web pages support multiple languages. Optionally, select supported languages through
language-preference settings in the browser.
Select Location Choose a location where the HP Embedded Web Server and product are being used.
Google Cloud With Google Cloud, you can use a computer or mobile device to print documents or photos
directly to a web-connected printer.
Setup Click Print Claim Sheet to send printer capabilities and model number to Google.
Registration instructions from Google will be printed. Make sure the product is connected to
a network with Internet access.
Web Proxy Configure a proxy server if there are issues enabling HP Web Services or connecting the
device to the Internet. If you are unsure of proxy settings, find the proxy configuration area
within the tools or preferences of your web browser.
Security Allows you to configure general security, access control, and stored data protection options,
as well as to manage certificates.
102 Chapter 4 Manage the scanner ENWW
