32
{
Delete—Click this button to delete fabrics (see " Deleting fabrics ").
{
Refresh—Click this button to obtain the latest fabric list.
Fabric list contents
{
Name—Fabric name. Click this link to view the fabric details (see " Viewing fabric details ").
{
Description—Description for the fabric.
{
Switch Count—Number of FCoE switches contained in the fabric.
{
Servers—Number of servers contained in the fabric.
{
Storage Devices—Number of storage devices contained in the fabric.
{
VSAN Count—Number of VSANs contained in the fabric.
{
Topology—Provides the link that you can click to open the SAN topology window. For
more information about the SAN topology, see " Managing a SAN topology ."
{
Modify—Click the Modify icon to modify the fabric (see " Modifying a fabric ").
Querying fabrics
1. On the upper right corner of the fabric list, enter a partial or complete fabric name in the query
control
, and click to display all fabrics that match the entered name.
Alternatively:
1. Click the Advanced icon to expand the query area, and specify one or more of the following
query criteria:
{
Name—Enter a partial or complete fabric name.
{
Description—Enter a partial or complete fabric description.
Empty fields are ignored.
2. Click Query to display all fabrics that match the query criteria.
Viewing fabric details
1. In the fabric list, click a fabric name to view the fabric details.
Fabric details include the following contents:
{
Fabric basic information:
− Name—Fabric name.
− Description—Description for the fabric.
− Switch Count—Number of FCoE switches contained in the fabric.
− VSAN Count—Number of VSANs contained in the fabric.
{
Switch—For information about managing FCoE switches in a fabric, see " Managing FCoE
switches ."
{
Server—For information about managing servers in a fabric, see " Managing servers ."
{
Storage—For information about managing storage devices in a fabric, see " Managing
storage devices ".
{
VSAN—For information about managing VSANs in a fabric, see " Managing VSANs ".
Adding a fabric
1. In the fabric list, click Add.
2. Configure the following parameters:
{
Name—Enter a name for the fabric. The name must be unique in VFM.
