Viewing the interface list of an RB
1. Access the RB List page.
2. Click the Operation icon for the RB.
3. Select Interface List from the shortcut menu.
The TRILL Interface List page displays all interfaces of the RB.
TRILL Interface List contents
{
Interface Status—State of the interface:
− Up—The interface is working normally.
− Down—The interface is enabled but the physical link is down.
− Disabled—The interface is disabled.
− Unmanaged—The interface is not managed by IMC.
− Unknown—IMC cannot obtain the interface state.
{
Interface Description—Interface type and number.
{
Enable TRILL Interface—Indicates whether or not TRILL is enabled on the interface: Enable or
Disable.
{
TRILL Port Type—Link type of the TRILL interface: Access, Trunk, or Hybrid. This field is empty if
TRILL is not enabled on the interface.
{
Modify—Click the Modify icon to modify the TRILL configuration of the interface. For more
information, see " Modifying TRILL configuration of an interface ."
NOTE:
The TRILL Interface List displays the TRILL configuration of the RB interfaces last synchronized from the RB.
To view the latest TRILL configuration of the RB interfaces, synchronize the RB first.
Batch configuring TRILL interfaces
1. Access the RB List page.
2. Click the Operation icon for the RB.
3. Select Interface List from the shortcut menu.
The TRILL Interface List page displays all ports of the RB.
4. Select the interfaces you want to configure.
5. Click Batch Interface Configuration.
The Batch Interface Configuration page appears.
6. Configure the following parameters:
{
Enable TRILL Interface—Select Yes or No from the list.
{
TRILL Port Type—Select the link type of the TRILL interface . Options are Access, Trunk, and
Hybrid.
{
DRB Priority—Specify the DRB priority of the TRILL interface. On a broadcast network, TRILL
must elect a DRB. An RB with a higher DRB priority is preferred. When two RBs have the same
DRB priority, the RB with a higher MAC address takes precedence.
{
Hello Interval (Seconds)—Specify the Hello interval. An RB advertises Hello frames at the Hello
interval to maintain a TRILL adjacency. The shorter the Hello interval, the faster the network
convergence. However, a shorter Hello interval consumes more system resources.
