OPERATION
Automatic Tab Positioning Features
When the Automatic soft key is pressed.
The display will prompt you to select which
Head you wish to setup.
Select Setup Option:
Press Run to tab using Job 1.
Status: Job #1 setup
Manual Automatic V-Tab BACK
NOTE: This feature can be used to
automatically position tabs when “side tabbing”.
Positions are based off the product length and
the number of tabs selected.
Select Tabber Head #1 or 2 to setup, or
Press Run to tab using Job 1.
Status: Automatic Setup
Head #1 Head #2 BACK 1 Tab – Tab is centered along length of media.
2 Tabs – Tabs are applied within 1” from each edge.
3 Tabs – Two tabs are applied within 1” from each
edge and one tab is centered.
From the Select Tabber Head screen, s elect the
head you want to setup.
If you select Head #1 the following choices will
appear:
Select Tabber Head # 1 or 2 to setup, or
Press RUN to tab using Job 1.
Status: Automatic Setup
Head #1 Head #2 BACK
ƒ Side Tab – Select this choice if you would like
to place tabs on the side of the media.
ƒ
Front Tab – Select this choice if you would like
to apply a tab to the front (leading edge) of the
media with Head #1. Also called Front Tabbing.
Select option to edit, or
Press RUN to tab using Job 1.
Status: Head #1 Automatic Setup
Side Tab Front Tab None BACK
ƒ
None – Select this choice if you do not want to
use Head #1. Disables Head #1.
ƒ
BACK – Brings you back to the previous
screen.
If you select Head #2 the following choices will
appear:
Select Tabber Head # 1 or 2 to setup, or
Press RUN to tab using Job 1.
Status: Automatic Setup
Head #1 Head #2 BACK
ƒ Side Tab – Select this choice if you would like
to place tabs on the side of the media.
ƒ
None – Select this choice if you do not want to
use Head #2. Disables Head #2.
ƒ
BACK – Brings you back to the previous
screen.
Select option to edit, or
Press RUN to tab using Job 1.
Status: Head #2 Automatic Setup
Side Tab None BACK
