Powermax125 Service Manual 808070
263
9 – Power Supply Component Replacement
13. If disconnected in step 12 on page 259, connect the wires to the RS-485 connector terminals, starting from the top,
in the following order:
red; black; brown; white; green.
Figure 116
1
2
3
4
5
1
2
3
4
5
