105 Contour Electrol E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
90505 White base for 12', 180" diag., 159" diag. and 164" diag. SCB-100/200 screens 1 $316.00
90506 White base for 200" diag., 184" diag. and 189" diag. SCB-100/200 screens 1 $330.00
13 88784 Pin end cap, white 1 $9.15
14 88822 Screw for end caps 8 $0.32
15a
White cover for standard, VPI, and LVC screens. See 15b for SCB-100/200 screens and LVC screens prior to
7/01/06.
89334 White cover for 60" and 72" diag. standard, VPI, and LVC screens 1 $126.00
89336 White cover for 70" and 84" diag. standard, VPI, and LVC screens 1 $137.00
89337WHITE White cover for 84", 96" diag., 100" diag., 92" diag. and 94" diag. standard, VPI, and LVC screens 1 $257.00
88836WHITE White cover for 8', 120" diag., 106" diag. and 109" diag. standard, VPI, and LVC screens 1 $273.00
94620 White cover for 110" diag. and 113" diag. standard, VPI, and LVC screens 1 $156.00
89339 White cover for 9', 119" diag. and 123" diag. standard, VPI, and LVC screens 1 $164.00
38023 White base for 130" diag. standard, VPI, and LVC screens 1 $172.00
98565WHITE White cover for 10', 150" diag., 133" diag. and 137" diag. standard, VPI, and LVC screens 1 $311.00
98566WHITE White cover for 12', 180" diag., 159" diag. and 164" diag. standard, VPI, and LVC screens 1 $316.00
89342 White cover for 200" diag., 184" diag. and 189" diag. standard, VPI, and LVC screens 1 $187.00
15b Order the following cover for current SCB-100/200 units and screens with LVC prior to 7/01/06
90521 White cover for 60" and 72" diag. SCB-100/200 screens 1 $131.00
90522 White cover for 70" and 84" diag. SCB-100/200 screens 1 $142.00
90523 White cover for 84", 96" diag., 100" diag., 92" diag. and 94" diag. SCB-100/200 screens 1 $152.00
38874 White cover for 8', 120" diag., 106" diag. and 109" diag. SCB-100/200 screens 1 $161.00
94622 White cover for 110" diag. and 113" diag. SCB-100/200 screens 1 $164.00
90525 White cover for 9', 119" diag. and 123" diag. SCB-100/200 screens 1 $168.00
38024 White cover for 130" diag. SCB-100/200 screens 1 $178.00
34415 White cover for 10', 150" diag., 133" diag. and 137" diag. SCB-100/200 screens 1 $182.00
90527 White cover for 12', 180" diag., 159" diag. and 164" diag. SCB-100/200 screens 1 $185.00
90528 White cover for 200" diag., 184" diag. and 189" diag. SCB-100/200 screens 1 $194.00
16 88779 Ceiling hanger 2 $13.65
17 88826 Screw for ceiling hangers 8 $0.80
18 44721 Hex nut, 1/4"-20 8 $0.27
19 88782 Ceiling hanger, hook 2 $10.25
20 88783 Motor end cap, white for standard and LVC screens 1 $9.15
34184 Motor end cap assy., white 240v for VPI screens 1 $191.00
93514 Motor end cap assy., white 120v for SCB-100 screens 1 $529.00
95018 Motor end cap assy., white 240v for SCB-100 screens 1 $529.00
96992 Motor end cap assy., white 120v for SCB-200 screens 1 $1,000.00
32610 Motor end cap assy., white 240v for SCB-200 screens 1 $1,000.00
21 84470 Connector assy., 120v 1 $7.00
84482 Connector assy., 240v 1 $7.00
22 89464 Screw for cover plate 1 $0.37
23 88785 Cover plate, motor end cap 1 $4.60
24 89055WHITE Cover, wire for standard, VPI, and LVC screens 1 $4.30
89580 Cover, wire for SCB-100/200 screens (not shown) 1 $5.00
89580 Cover, wire LVC screens (prior to 7/01/06) 1 $5.00
25 77814 Screw for wire cover 2 $0.37
26 37138 Roller bracket assy., motor end (prior to 7/16/07) (not shown) 1 $1.75
92383 Roller bracket assy., motor end for 10' x 10' and below screens 1 $25.00
28355 Roller bracket assy., motor end for over 10' x 10' screens (not shown) 1 $25.00
