Tensioned Advantage® (over 14’ W)
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
12769
Fabric and roller assy., Parallax Stratos 1.0 120" x 192" - 226" diag.
1
$5,116.00
22359
Fabric and roller assy., HD Progressive 0.9 120" x 192" - 226" diag.
1
$4,872.00
22360
Fabric and roller assy., HD Progressive 1.1 120" x 192" - 226" diag.
1
$4,872.00
21547
Fabric and roller assy., HD Progressive 1.1 Contrast 120" x 192" - 226" diag.
1
$4,872.00
29201
Fabric and roller assy., HD Progressive 1.3 120" x 192" - 226" diag.
1
$4,872.00
21549
Fabric and roller assy., HD Progressive ReView 0.9 120" x 192" - 226" diag.
1
$4,872.00
21543
Fabric and roller assy., Da-Mat 120" x 192" - 226" diag.
1
$4,015.00
21548
Fabric and roller assy., Da-Tex 120" x 192" - 226" diag.
1
$4,477.00
Video (4:3) Format
39334
Fabric and roller assy., Da-Mat 126" x 168" - 210" diag.
1
$3,594.00
39341
Fabric and roller assy., Da-Mat 132" x 176" - 220" diag.
1
$3,741.00
39348
Fabric and roller assy., Da-Mat 144" x 192" - 240" diag.
1
$4,092.00
36802
Fabric and roller assy., Da-Mat 162" x 216" - 270" diag.
1
$4,206.00
6
35905
Bolt for roller brackets
8
$1.75
35903
Nut for roller brackets
8
$1.17
95073
Washer for roller brackets
8
$0.37
7
35917
Bracket assy., pin end
1
$25.40
8
83017
Flanged bearing
1
$50.00
9
44731
Bolt to attach bearing to the bracket assy.
2
$0.23
44733
Washer for roller bracket assy.
2
$0.09
10
37678
Access door assy., 198 1/2" and 210" diag. screens
1
$576.00
37680
Access door assy., 225" for 240" diag. screens
1
$576.00
37679
Access door assy., 207 1/2" for 220" diag. screens
1
$576.00
37681
Access door assy., 250 1/2" for 270" diag. screens
1
$740.00
37682
Access door assy., 220" for 220" HD diag. screens
1
$576.00
37683
Access door assy., 246" for 247" diag. screens
1
$740.00
37684
Access door assy., 272" for 275" diag. screens
1
$740.00
37685
Access door assy., 293 1/2" for 298" diag. screens
1
$740.00
70665
Access door assy., 204 3/4" for 208" diag. screens
1
$576.00
70815
Access door assy., 221 1/2" for 226" diag. screens
1
$576.00
11
35907
Screws to attach the end caps
8
$0.80
12
35885
Pin end cap assy.
1
$58.50
13
35888
Door bracket assy.
2
$7.80
14
80874
Nut to attach bracket assy.
4
$0.32
15
Aluminum white case
HDTV (16:9) Format
37422
Aluminum white case for 220"HD diag. screens
1
$6,000.00
37423
Aluminum white case for 247" diag. screens
1
$7,500.00
37424
Aluminum white case for 275" diag. screens
1
$7,500.00
37425
Aluminum white case for 298" diag. screens
1
$7,500.00
Wide (16:10) Format
70664
Aluminum white case for 208" diag. screens
1
$6,000.00
70814
Aluminum white case for 226" diag. screens
1
$6,000.00
Video (4:3) Format
37418
Aluminum white case for 210" diag. screens
1
$6,000.00
37420
Aluminum white case for 240" diag. screens
1
$6,000.00
37419
Aluminum white case for 220" diag. screens
1
$6,000.00
37421
Aluminum white case for 270" diag. screens
1
$7,500.00
