Da-Lite 37989KIT Motor Drive Wheel Kit (120 VAC) - Manual (Page 49)

49 Advantage
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
91724 White door for 10', 150" diag., 133" diag. and 137" diag. SCB-100/200 screens 1 $116.00
84565 White door for 12', 180" diag., 159" diag. and 164" diag. SCB-100/200 screens 1 $117.00
91725 White door for 200" diag., 184" diag. and 189" diag. SCB-100/200 screens 1 $119.00
12 79659 Screw for door 2 $0.16
13 84225 Door bracket 2 $3.20
14 72537 Screw for door bracket (pre August 2016) 2 $0.32
10908 Screw for door bracket (August 2016 and later) 2 $0.32
15 50747 Screw for universal end cap 8 $0.16
16 96336WHITE Pin end cap, white 1 $22.65
17a
Case for standard screens with LVC. See 17b for screens with SCB-100 / SCB-200 or screens with LVC built
prior to 7/01/06.
84130 White case for 60" and 72" diag. standard and LVC screens 1 $488.00
84229 White case for 70" and 84" diag. standard and LVC screens 1 $544.00
84230 White case for 84", 96" diag., 100" diag., 92" diag. and 94" diag. standard and LVC screens 1 $611.00
84231 White case for 8', 120" diag., 106" diag. and 109" diag. standard and LVC screens 1 $675.00
84533 White case for 110" diag. and 113" diag. standard and LVC screens 1 $692.00
84232 White case for 9', 119" diag. and 123" diag. standard and LVC screens 1 $742.00
34933 White case for 130" diag. standard and LVC screens 1 $763.00
84234 White case for 10', 150" diag., 133" diag. and 137" diag. standard and LVC screens 1 $785.00
36380 White case for 12', 180" diag., 159" diag. and 164" diag. standard and LVC screens 1 $868.00
84546 White case for 200" diag., 184" diag. and 189" diag. standard and LVC screens 1 $956.00
17b Order the following case for LVC screens prior to 7/01/06.
84130 White case for 50" SCB-100/200 screens 1 $488.00
84229 White case for 60" and 72" diag. SCB-100/200 screens 1 $544.00
91716 White case for 70" and 84" diag. SCB-100/200 screens 1 $554.00
91717 White case for 84", 96" diag., 100" diag., 92" diag. and 94" diag. SCB-100/200 screens 1 $623.00
92882 White case for 8', 120" diag., 106" diag. and 109" diag. SCB-100/200 screens 1 $684.00
84536 White case for 110" diag. and 113" diag. SCB-100/200 screens 1 $705.00
91718 White case for 9', 119" diag. and 123" diag. SCB-100/200 screens 1 $753.00
84539 White case for 130" diag. SCB-100/200 screens 1 $785.00
91719 White case for 10', 150" diag., 133" diag. and 137" diag. SCB-100/200 screens 1 $807.00
84544 White case for 12', 180" diag., 159" diag. and 164" diag. SCB-100/200 screens 1 $944.00
91720 White case for 200" diag., 184" diag. and 189" diag. SCB-100/200 screens 1 $1,034.00
18 96342 Motor end cap, white 120v 1 $55.00
96343 Motor end cap, white 240v 1 $80.00
96342L Motor end cap, white 120v for LVC screens 1 $55.00
96343L Motor end cap, white 240v for LVC screens 1 $55.00
96334WHITE Motor end cap, white for SCB-100/200 screens 1 $22.65
96335WHITE Motor end cap, white with internal junction box (prior to 4/01/07) (not shown) 1 $22.65
34165WHITE Motor end cap, white with internal junction box (not shown) 1 $22.65
19 99584WASH Junction box 1 $11.25
94501 Junction box, internal (not shown) 1 $11.25
20 99585WASH Junction box cover 1 $6.00
94503WHITE Junction box cover, internal (not shown) 1 $2.65
21 86809 Connector assy., 120v for standard LVC screens (not shown) 1 $4.10
86812 Connector assy., 240v for standard LVC screens (not shown) 1 $4.10
84470 Connector assy., 120v 1 $7.00
84482 Connector assy., 240v 1 $7.00
