Cosmopolitan (Over 12’ W)
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
5
96902
Roller assy., 4.5" diam. for 12' x 12' screens
1
$380.00
96903
Roller assy., 4.5" diam. for 200" diag. And 189" diag. screens
1
$390.00
96904
Roller assy., 4.5" diam. for 14', 210" diag., and 188" diag. screens
1
$444.00
97854
Roller assy., 4.5" diam. for 208" diag. screens
1
$465.00
96905
Roller assy., 4.5" diam. for 16', 240" diag., 216" diag. and 222" diag. screens
1
$487.00
6
96910BLACK
Roller bracket assy., pin end (for screens manufactured prior to 1-05-15, it will be necessary to also replace
#31)
1
$38.00
7
44752
Nut for mounting brackets and hanger bracket
12
$0.18
8
95073
Washer for mounting brackets and hanger bracket
12
$0.37
9
93506
Screw for mounting brackets and hanger bracket
12
$1.75
10
37480
Ironing board., for 12' x 12' screens
1
$93.50
37481REPL
Ironing board., for 200" diag. and 189" diag. screens
1
$101.00
37482
Ironing board., for 14', 210" diag. and 188" diag. screens
1
$101.00
70911
Ironing board., for 208" diag. screens
1
$103.00
37483REPL Ironing board., for 16', 240" diag., 216" diag. and 222" diag. screens
1
$107.00
11
87056
Screw for ironing board
5-9
$0.20
12
37487
Nut for ironing board
5-9
$0.59
13
37484
Bracket for ironing board
5-9
$3.90
14
28947
Screw for ironing board
5-9
$0.49
15
12390
Screw for hanger bracket, White (for screens with standard white case)
4-6
$0.44
12391
Screw for hanger bracket, Black (for screens with black case)
4-6
$0.44
16
96894WHITE White base for 12' x 12' screens
1
$519.00
96895WHITE White base for 200" diag. and 189" diag. screens
1
$531.00
96896WHITE White base for 14', 210" diag., and 188" diag. screens
1
$601.00
97852WHITE White base for 208" diag. screens
1
$629.00
96897WHITE White base for 16', 240" diag., 216" diag. and 222" diag. screens
1
$656.00
17
96301
Pin end cap, white
1
$12.70
18
88822
Screw for end caps, white
12
$0.32
19
29075
Hanger bracket for 12' x 12' screens
1
$84.30
96704
Hanger bracket for 14', 200" diag., 210" diag. 188" diag. and 189" diag. screens
1
$84.30
96311
Hanger bracket for 16', 240" diag., 216" diag. 208" diag. and 222" diag. screens
1
$90.80
20
96650
Hanger bracket, white
4
$29.50
21
96898WHITE White cover for 12' x 12' screens
1
$400.00
96899WHITE White cover for 200" diag. and 189" diag. screens
1
$413.00
96900WHITE White cover for 14', 210" diag., and 188" diag. screens
1
$475.00
97853WHITE White cover for 208" diag. screens
1
$497.00
96901WHITE White cover for 16', 240" diag., 216" diag. and 222" diag. screens
1
$519.00
22
96923
Cover retainer, white
2
$3.30
23
25736
Screw for cover retainer, white
4
$0.27
24
54520
Connector, cable 3/8"
1
$1.27
25
96303
Motor end cap, white
1
$12.70
26
84470
Connector assy., 120v
1
$7.00
84482
Connector assy., 240v
1
$7.00
27
89464
Screw for cover plate, white
1
$0.37
28
96305
Cover plate, motor end cap
1
$5.30
29
44799
Ground screw, #10-32 for wire cover
1
$0.32
30
99501WHITE Cover, wire
1
$2.65
31
28692BLACK Roller bracket, motor end (for screens manufactured prior to 1-05-15, it will be necessary to also replace #6)
1
$38.00
