Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
59107 Fabric, Matte White 72" x 96" 1 $294.00
92711 Fabric, High Contrast Matte White 72" x 96" 1 $322.00
57965 Fabric, Matte White 96" x 96" 1 $331.00
93185 Fabric, High Contrast Matte White 96" x 96" 1 $366.00
13 45766 Anchor nut, .156 long, zinc 1 $0.91
14 45778 Beveled washer for bottom tube 1 $1.85
15 57923 Spring button assy., handle/tube 2 $3.30
16/20 45757 Handle pivot assy, fabric lock 1 $45.00
17 74338 Flat washer for handle pivot 1 $0.15
18 76203 Hex nut for handle pivot 1 $0.81
19 45766BLK Anchor nut, .250 long, black 1 $8.30
21 45379 Bottom tube for 60" screens 1 $28.70
45372 Bottom tube for 70", 84" and 96" screens 1 $37.40
22 73553 Tripod assy. for 60", 70", 84" and 96" screens 1 $89.40
23 76292 Screw for leg lock 2 $0.16
24 48082 Roll pin to secure leg shoes 3 $0.27
25 45754 Leg shoe, black plastic 3 $0.91
26 76290 Leg release, black plastic 1 $6.60
27 46023 Spring for plastic leg release 1 $0.53
28 76133 Leg lock guide, plastic 1 $0.53
29 76291 Screw for plastic leg lock 1 $0.27
For complete leg lock assy., order as follows: (includes #26-30)
77554 Leg lock assy., plastic 1 $9.40
30 82986 Spring end cap, black plastic for 1 3/8" roller 1 $4.60
83640 Spring end cap, black plastic for 1 3/4" roller 1 $4.60
31 73388 Screw for end caps, black 6 $0.23
32 74871 Case and centerband assy. for 60" screens, black 1 $32.00
74875 Case and centerband assy. for 70" screens, black 1 $33.00
74878 Case and centerband assy. for 84" screens, black 1 $38.00
74881 Case and centerband assy. for 96" screens, black 1 $40.00
89094 Case and centerband assy. for 60" screens, carpeted black 1 $93.90
89095 Case and centerband assy. for 70" screens, carpeted black 1 $105.00
89096 Case and centerband assy. for 84" screens, carpeted black 1 $126.00
89097 Case and centerband assy. for 96" screens, carpeted black 1 $150.00
33 82985 Pin end cap, black plastic 1 $4.60
34 80762 Roller plug for 1 3/8" roller 1 $1.75
80765 Roller plug for 1 3/4" roller 1 $2.30
35 45313 1 3/8" diam. roller for 60" screens 1 $8.60
45317 1 3/8" diam. roller for 70" screens 1 $9.40
46277 1 3/4" diam. roller for 84" screens 1 $12.20
46279 1 3/4" diam. roller for 96" screens 1 $13.60
36 57864 Spring assy. for 1 3/8" roller 1 $13.80
58353 Spring assy. for 1 3/4" roller 1 $28.10
For complete roller assy., order as follows: (includes #35-37)
57766 Camlock roller assy. for 60" screens 1 $22.05
57767 Camlock roller assy. for 70" screens 1 $23.70
58350 Camlock roller assy. for 84" screens 1 $42.80
58351 Camlock roller assy. for 96" screens 1 $44.10
