125
DL–0664 (Rev 3) 07.21
© 2021 Legrand AV Inc.
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
32 38845RPL Motor assy., 120v 1 $585.00
20996RPL Motor assy., 120v with built-in LVC 1 $681.00
32749RPL Motor assy., 240v 1 $585.00
32625RPL Motor assy., 240v with built-in LVC 1 $800.00
33 81652 Hair cotter pin, 3/8" - 3/4" x 2 1/2" for 12' x 12' screens 1 $0.47
97290 Hair cotter pin, 5/16" - 3/8" x 1 5/8" for 200" diag. and over screens 1 $0.47
34 99607 Built-in LVC Motor Hardware Kit (not shown) 1 $120.00
80575 Wall switch, 120v white (not shown) 1 $77.00
40961 Wall switch, 120v ivory (not shown) 1 $77.00
11147 Wall switch, 240v white double push putton (not shown) 1 $77.00
38463E Wall switch, 240v white rocker (not shown) 1 $77.00
