31 Tensioned Advantage® (over 14’ W with Closure Door)
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 44839 Screw for slat cap assy. 4 $0.27
2 98895 Slat cap assy. (includes #1) 2 $40.00
3 10685 Tab 14-40 $0.37
4 75658
Line, chalk and mason black (per foot). Figure one side at approximately height of fabric + 2' + any extra
needed
Per size $0.23
5 Fabric and roller assemblies include #2, 3 and 4
HDTV (16:9) Format
12764 Fabric and roller assy., Parallax Stratos 1.0 108" x 192" - 220" HD diag. 1 $4,608.00
22361 Fabric and roller assy., HD Progressive 0.9 108" x 192" - 220" HD diag. 1 $4,388.00
22362 Fabric and roller assy., HD Progressive 1.1 108" x 192" - 220" HD diag. 1 $4,388.00
39359 Fabric and roller assy., HD Progressive 1.1 Contrast 108" x 192" - 220" HD diag. 1 $4,388.00
29196 Fabric and roller assy., HD Progressive 1.3 108" x 192" - 220" HD diag. 1 $4,388.00
39361 Fabric and roller assy., HD Progressive ReView 0.9 108" x 192" - 220" HD diag. 1 $4,388.00
39355 Fabric and roller assy., Da-Mat 108" x 192" - 220" HD diag. 1 $3,616.00
39360 Fabric and roller assy., Da-Tex 108" x 192" - 220" HD diag. 1 $4,031.00
12765 Fabric and roller assy., Parallax Stratos 1.0 121" x 216" - 247" diag. 1 $5,194.00
22363 Fabric and roller assy., HD Progressive 0.9 121" x 216" - 247" diag. 1 $4,946.00
22364 Fabric and roller assy., HD Progressive 1.1 121" x 216" - 247" diag. 1 $4,946.00
36813 Fabric and roller assy., HD Progressive 1.1 Contrast 121" x 216" - 247" diag. 1 $4,946.00
29197 Fabric and roller assy., HD Progressive 1.3 121" x 216" - 247" diag. 1 $4,946.00
36815 Fabric and roller assy., HD Progressive ReView 0.9 121" x 216" - 247" diag. 1 $4,946.00
36809 Fabric and roller assy., Da-Mat 121" x 216" - 247" diag. 1 $4,076.00
36814 Fabric and roller assy., Da-Tex 121" x 216" - 247" diag. 1 $4,505.00
12766 Fabric and roller assy., Parallax Stratos 1.0 135" x 240" - 275" diag. 1 $5,708.00
22353 Fabric and roller assy., HD Progressive 0.9 135" x 240" - 275" diag. 1 $5,436.00
22354 Fabric and roller assy., HD Progressive 1.1 135" x 240" - 275" diag. 1 $5,436.00
36820 Fabric and roller assy., HD Progressive 1.1 Contrast 135" x 240" - 275" diag. 1 $5,436.00
29198 Fabric and roller assy., HD Progressive 1.3 135" x 240" - 275" diag. 1 $5,436.00
36822 Fabric and roller assy., HD Progressive ReView 0.9 135" x 240" - 275" diag. 1 $5,436.00
36816 Fabric and roller assy., Da-Mat 135" x 240" - 275" diag. 1 $4,479.00
36821 Fabric and roller assy., Da-Tex 135" x 240" - 275" diag. 1 $4,918.00
12767 Fabric and roller assy., Parallax Stratos 1.0 146" x 260" - 298" diag. 1 $6,026.00
22355 Fabric and roller assy., HD Progressive 0.9 146" x 260" - 298" diag. 1 $5,740.00
22356 Fabric and roller assy., HD Progressive 1.1 146" x 260" - 298" diag. 1 $5,740.00
36827 Fabric and roller assy., HD Progressive 1.1 Contrast 146" x 260" - 298" diag. 1 $5,740.00
29199 Fabric and roller assy., HD Progressive 1.3 146" x 260" - 298" diag. 1 $5,740.00
36829 Fabric and roller assy., HD Progressive ReView 0.9 146" x 260" - 298" diag. 1 $5,740.00
36823 Fabric and roller assy., Da-Mat 146" x 260" - 298" diag. 1 $4,730.00
36828 Fabric and roller assy., Da-Tex 146" x 260" - 298" diag. 1 $5,086.00
Wide (16:10) Format
12768 Fabric and roller assy., Parallax Stratos 1.0 110" x 176" - 208" diag. 1 $4,766.00
22357 Fabric and roller assy., HD Progressive 0.9 110" x 176" - 208" diag. 1 $4,540.00
22358 Fabric and roller assy., HD Progressive 1.1 110" x 176" - 208" diag. 1 $4,540.00
21540 Fabric and roller assy., HD Progressive 1.1 Contrast 110" x 176" - 208" diag. 1 $4,540.00
29200 Fabric and roller assy., HD Progressive 1.3 110" x 176" - 208" diag. 1 $4,540.00
21542 Fabric and roller assy., HD Progressive ReView 0.9 110" x 176" - 208" diag. 1 $4,540.00
21536 Fabric and roller assy., Da-Mat 110" x 176" - 208" diag. 1 $3,741.00
21541 Fabric and roller assy., Da-Tex 110" x 176" - 208" diag. 1 $4,176.00
