193 Model C with CSR E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 82998 Screw for dampener assy. for 3" roller 3 $0.16
2 38855 CSR and spring assy. for 60" thru 72" screens (Prior to 2-8-19) 1 $97.30
38855 CSR and spring assy. for 60" thru 96" screens. For 1 3/4" roller (2-8-19 and later) 1 $97.30
79090 CSR assy. for 3" roller 84" - 96" (Prior to 2-8-19) 1 $271.00
79090 CSR assy. for 3" roller - See note #1 $271.00
93450 CSR assy. for 10' x 10', 9' x 12', 12' x 12', 180" diag. and 200" diag. screens - See note #2 1 $271.00
3 25736 Screw for end caps 10 $0.27
4 20742 CSR end cap assy., white for 1 3/4" roller 1 $19.55
39888 CSR end cap assy., white for 3" roller 1 $42.80
5 38043 CSR cover plate, white 1 $2.30
6 89464 Screw for cover plate 1 $0.37
7 78343 White case for 60" and 72" diag. screens with 1 3/4" roller 1 $48.30
78344 White case for 70" and 84" diag. screens with 1 3/4" roller 1 $52.80
33636WHITE White case for 72" screens with 1 3/4" roller 1 $55.80
78345 White case for 84", 100" diag., 92" diag. and 94" diag. screens with 3" roller (Prior to 2-8-19) 1 $63.70
12182 White case for 84", 100" diag., 92" diag. and 94" diag. screens with 1 3/4" roller (2-8-19 and later) 1 $63.70
78283 White case for 8', 120" diag., 106" diag. and 109" diag. screens with 3" roller (Prior to 2-8-19) 1 $71.30
12183 White case for 8', 120" diag., 106" diag. and 109" diag. screens with 1 3/4" roller (2-8-19 and later) 1 $71.30
94724 White case for 110" diag. and 113" diag. screens 1 $73.40
78312 White case for 9', 119" diag. and 123" diag. screens 1 $75.70
35021WHITE White case for 130" diag. screens 1 $76.90
78307 White case for 10', 150" diag., 133" diag. and 137" diag. screens 1 $80.00
78313 White case for 12', 180" diag., 159" diag. and 164" diag. screens 1 $92.10
92026 White case for 200" diag. screens 1 $94.40
8 37237 Spring end cap, white for 1 3/4" roller (prior to 1-17-12) 1 $5.85
20738 Spring end cap, white for 1 3/4" roller 1 $5.85
37245 Spring end cap, white for 3" roller 1 $5.85
9 82998 Screw for spring assy. for 3" roller 3 $0.16
10 Roller assemblies include #1, 2, 9 and 15
32852 1 3/4" roller assy. for 60" and 72" diag. Screens (after 1-17-12) 1 $107.00
32853 1 3/4" roller assy. for 70" and 84" diag. Screens (after 1-17-12) 1 $107.00
21934 1 3/4" roller assy. for 72" screens (after 1-17-12) 1 $107.00
80185 Roller assy. for 84", 100" diag., 92" diag. and 94" diag. screens (Prior to 2-8-19) 1 $421.00
80186 Roller assy. for 8' and 120" diag. screens (Prior to 2-8-19) 1 $423.00
32855 1 3/4" Roller assy. for 84", 100" diag., 92" diag. and 94" diag. screens (2-8-19 and later) 1 $111.00
32856 1 3/4" Roller assy. for 8', 120" , 106", 109" diag. screens (2-8-19 and later) 1 $112.00
80192 Roller assy. for 110" diag. and 113" diag. screens 1 $424.00
80187 Roller assy. for 9', 119" diag. and 123" diag. screens 1 $426.00
35003 Roller assy. for 130" diag. screens 1 $428.00
80188 Roller assy. for 8' x 10', 150" diag. 133" diag. and 137" diag. screens 1 $431.00
36377 Roller assy. for 10' x 10' screens 1 $431.00
80189 Roller assy. for 12' and 180" diag. screens 1 $433.00
36378 Roller assy. for 159" diag. and 164" diag. screens 1 $433.00
86831 Roller assy. for 200" diag. screens 1 $446.00
11 44726 Screw for dog for 3" roller 1 $0.29
12 98223 Pawl (dog) for 3" roller 1 $1.50
13 57705 Plug and spear assy. for 3" roller (includes #11 and 12) 1 $31.50
