175 Imager E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 47441 Snap stud to snap fabric onto frame 26-72 $0.59
2 52751 Screw to assemble frame 8 $0.27
3 ----- Frame Assembly - No Longer Available 1 -----
4 47491 Black cap for fabric 34-76 $0.37
5 47490 Heavy socket for fabric snaps of corners (not shown) 4 $0.37
6 47489 Light socket for all fabric snaps except corners (not shown) 30-72 $0.37
7 Fabric assemblies include #4,5 and 6
HDTV (16:9) Format
38425 Fabric assy., HD Progressive 0.6 37.5" x 67" - 77" diag. 1 $507.00
37808 Fabric assy., HD Progressive 0.9 37.5" x 67" - 77" diag. 1 $507.00
39160 Fabric assy., HD Progressive 1.1 37.5" x 67" - 77" diag. 1 $507.00
20554 Fabric assy., HD Progressive 1.1 Perf 37.5" x 67" - 77" diag. 1 $935.00
24902 Fabric assy., HD Progressive 1.3 37.5" x 67" - 77" diag. 1 $507.00
93276 Fabric assy., HD Progressive ReView 0.9 37.5" x 67" - 77" diag. 1 $507.00
93268 Fabric assy., Da-Mat 37.5" x 67" - 77" diag. 1 $418.00
93270 Fabric assy., Da-Tex 37.5" x 67" - 77" diag. 1 $573.00
38426 Fabric assy., HD Progressive 0.6 40.5" x 72" - 82" diag. 1 $541.00
37809 Fabric assy., HD Progressive 0.9 40.5" x 72" - 82" diag. 1 $541.00
39161 Fabric assy., HD Progressive 1.1 40.5" x 72" - 82" diag. 1 $541.00
20555 Fabric assy., HD Progressive 1.1 Perf 40.5" x 72" - 82" diag. 1 $968.00
24903 Fabric assy., HD Progressive 1.3 40.5" x 72" - 82" diag. 1 $541.00
96938 Fabric assy., HD Progressive ReView 0.9 40.5" x 72" - 82" diag. 1 $541.00
96930 Fabric assy., Da-Mat 40.5" x 72" - 82" diag. 1 $446.00
96932 Fabric assy., Da-Tex 40.5" x 72" - 82" diag. 1 $617.00
38427 Fabric assy., HD Progressive 0.6 45" x 80" - 92" diag. 1 $605.00
37810 Fabric assy., HD Progressive 0.9 45" x 80" - 92" diag. 1 $605.00
39162 Fabric assy., HD Progressive 1.1 45" x 80" - 92" diag. 1 $605.00
20556 Fabric assy., HD Progressive 1.1 Perf 45" x 80" - 92" diag. 1 $1,033.00
24904 Fabric assy., HD Progressive 1.3 45" x 80" - 92" diag. 1 $605.00
83468 Fabric assy., HD Progressive ReView 0.9 45" x 80" - 92" diag. 1 $605.00
83746 Fabric assy., Da-Mat 45" x 80" - 92" diag. 1 $499.00
83747 Fabric assy., Da-Tex 45" x 80" - 92" diag. 1 $705.00
38428 Fabric assy., HD Progressive 0.6 49" x 87" - 100" HD diag. 1 $692.00
37811 Fabric assy., HD Progressive 0.9 49" x 87" - 100" HD diag. 1 $692.00
39163 Fabric assy., HD Progressive 1.1 49" x 87" - 100" HD diag. 1 $692.00
20557 Fabric assy., HD Progressive 1.1 Perf 49" x 87" - 100" HD diag. 1 $1,120.00
24905 Fabric assy., HD Progressive 1.3 49" x 87" - 100" HD diag. 1 $692.00
96692 Fabric assy., HD Progressive ReView 0.9 49" x 87" - 100" HD diag. 1 $692.00
96684 Fabric assy., Da-Mat 49" x 87" - 100" HD diag. 1 $570.00
96686 Fabric assy., Da-Tex 49" x 87" - 100" HD diag. 1 $746.00
38429 Fabric assy., HD Progressive 0.6 52" x 92" - 106" diag. 1 $781.00
37812 Fabric assy., HD Progressive 0.9 52" x 92" - 106" diag. 1 $781.00
39164 Fabric assy., HD Progressive 1.1 52" x 92" - 106" diag. 1 $781.00
20558 Fabric assy., HD Progressive 1.1 Perf 52" x 92" - 106" diag. 1 $1,210.00
24906 Fabric assy., HD Progressive 1.3 52" x 92" - 106" diag. 1 $781.00
80005 Fabric assy., HD Progressive ReView 0.9 52" x 92" - 106" diag. 1 $781.00
79116 Fabric assy., Da-Mat 52" x 92" - 106" diag. 1 $644.00
79117 Fabric assy., Da-Tex 52" x 92" - 106" diag. 1 $785.00
