62 Advantage (over 14’ W)
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
Video (4:3) Format
21633 Fabric and roller assy., Matte White 123" x 164" - 210" diag. 1 $2,233.00
21634 Fabric and roller assy., Matte White 141" x 188" - 240" diag. 1 $2,612.00
21635 Fabric and roller assy., Matte White 159" x 212" - 265" diag. 1 $3,377.00
21636 Fabric and roller assy., Matte White 177" x 236" - 295" diag. 1 $4,703.00
21632 Fabric and roller assy., Matte White 213" x 284" - 355" diag. 1 $7,597.00
Square Format
21622 Fabric and roller assy., Matte White 10' 6" x 14' 1 $2,266.00
21623 Fabric and roller assy., Matte White 14' x 14' 1 $2,716.00
21624 Fabric and roller assy., Matte White 12' x 16' 1 $2,656.00
21625 Fabric and roller assy., Matte White 16' x 16' 1 $3,275.00
21626 Fabric and roller assy., Matte White 13' 6" x 18' 1 $3,377.00
21627 Fabric and roller assy., Matte White 18' x 18' 1 $4,475.00
21628 Fabric and roller assy., Matte White 15' x 20' 1 $4,703.00
21629 Fabric and roller assy., Matte White 20' x 20' 1 $6,007.00
21630 Fabric and roller assy., Matte White 16' 6" x 22' 1 $5,451.00
21631 Fabric and roller assy., Matte White 22' x 22' 1 $6,637.00
5 81662 Roller assy., 5.75" diam. for 14' and 210" diag. screens 1 $581.00
70756 Roller assy., 5.75" diam. for 208" diag. screens 1 $604.00
81663 Roller assy., 5.75" diam. for 16', 240" diag., 216" diag. and 222" diag. screens 1 $625.00
81664 Roller assy., 5.75" diam. for 18', 265" diag. and 243" diag. screens 1 $669.00
89110 Roller assy., 7" diam. for 20', 295" diag. and 271" diag. screens 1 $889.00
89111 Roller assy., 7" diam. for 22' screens 1 $944.00
89112 Roller assy., 7" diam. for 24' screens 1 $1,011.00
6 35905 Bolt for roller brackets 8 $1.75
35903 Nut for roller brackets 8 $1.17
95073 Washer for roller brackets 8 $0.37
7 35917 Bracket assy., pin end 1 $25.40
8 83017 Flanged bearing 1 $50.00
9 44731 Bolt to attach bearing to the bracket assy. 2 $0.23
44733 Washer for roller bracket assy. 2 $0.09
10 37672 Access door assy., 182 3/4" for 14' screens 1 $576.00
32831 Access door assy., 194 3/4" for 15' screens 1 $576.00
37673 Access door assy., 206 3/4" for 16' screens 1 $576.00
37674 Access door assy., 230 3/4" for 18' screens 1 $740.00
37675 Access door assy., 254 3/4" for 20' screens 1 $740.00
37676 Access door assy., 278 3/4" for 22' screens 1 $740.00
37677 Access door assy., 302 3/4" for 24' screens 1 $740.00
11 87056 Screw for ironing board 10-18 $0.20
37487 Nut for ironing board 10-18 $0.59
35891 Bracket for ironing board 5-9 $3.30
12 37482 Ironing board for 14' and 210" diag. screens 1 $101.00
70911 Ironing board for 208" diag. screens 1 $103.00
37483REPL Ironing board for 16', 240" diag., 216" diag. and 222" diag. screens 1 $107.00
21935 Ironing board for 18', 265" diag. and 243" diag. screens 1 $117.00
21936 Ironing board for 20', 295" diag. and 271" diag. screens 1 $119.00
21937 Ironing board for 22' screens 1 $120.00
39202 Ironing board for 24' screens 1 $124.00
