23
DL–0624 (Rev. 7) 07.21
© 2021 Legrand AV Inc.
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
24 20612SKIT Motor assy., 120v Silent for standard and SCB-100/200 screens with 3.25" rollers up to and including 10' x 10' 1 $487.00
38890LSKIT Motor assy., 120v Silent for LVC and VPI screens with 3.25" rollers up to and including 10' x 10' 1 $585.00
37989KIT Motor assy., 120v for standard and SCB-100/200 screens over 10' wide with 3.25" rollers 1 $390.00
38890KIT Motor assy., 120v for LVC and VPI screens over 10' wide with 3.25" rollers 1 $487.00
20614SKIT Motor assy., 240v Silent for standard and SCB-100/200 with 3.25" rollers up to and including 10' x 10' 1 $487.00
32645LSKIT Motor assy., 240v Silent for LVC screens with 3.25" rollers up to and including 10' x 10' before 6/11/2018 1 $585.00
12279KIT Motor assy., 240v Silent for LVC screens with 3.25" rollers up to and including 10' x 10' 6/11/2018 and after 1 $585.00
32692KIT Motor assy., 240v for standard and SCB-100/200 screens over 10' wide with 3.25" rollers 1 $390.00
94785TABS Drive wheel/rubber mount for screens purchased before 5/05/08 (not shown) 1 $40.00
25 97290 Hair cotter pin, 5/16" - 3/8" x 1 5/8" 1 $0.47
26 97319 Hangers and hardware for under 8' screens (not shown) 1 $15.75
97320 Hangers and hardware for 8' and over screens (not shown) 1 $23.15
38885 Built-in motor hardware kit (not shown) 1 $298.00
99607 ILT/LVC motor hardware kit (not shown) 1 $120.00
38885B Built-in motor hardware kit for case only (not shown) 1 $94.40
99607B ILT/LVC motor hardware kit for case only (not shown) 1 $94.40
80575 Wall switch, 120v white (not shown) 1 $77.00
40961 Wall switch, 120v ivory (not shown) 1 $77.00
11147 Wall switch, 240v white double push putton (not shown) 1 $77.00
38463E Wall switch, 240v white rocker (not shown) 1 $77.00
