127 Designer Contour/Cinema Electrol E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 46339 Slat, 3/8" diam. for 60" and 72" diag. screens 1 $9.75
46340 Slat, 3/8" diam. for 70", 84" diag. and 77" diag. screens 1 $10.30
46341 Slat, 3/8" diam. for 84", 96" diag., 100" diag. and 92" diag. screens 1 $10.85
46342 Slat, 3/8" diam. for 8', 120" diag. and 106" diag. screens 1 $12.15
2 46763 Slat cap, black 2 $0.32
3 83383 Tape for pocket, black 2 $0.64
4 Replacment Fabric
HDTV (16:9) Format
97967 Fabric, Matte White 37 1/2" x 67" - 77" diag. 1 $142.00
97968 Fabric, High Contrast Matte White 37 1/2" x 67" - 77" diag. 1 $155.00
70054 Fabric, Matte White 45" x 80" - 92" diag. 1 $213.00
92778 Fabric, High Contrast Matte White 45" x 80" - 92" diag. 1 $230.00
70055 Fabric, Matte White 52" x 92" - 106" diag. 1 $294.00
92779 Fabric, High Contrast Matte White 52" x 92" - 106" diag. 1 $322.00
Video (4:3) Format
70051 Fabric, Matte White 43" x 57" - 72" diag. 1 $116.00
92773 Fabric, High Contrast Matte White 43" x 57" - 72" diag. 1 $127.00
70052 Fabric, Matte White 50" x 67" - 84" diag. 1 $142.00
92774 Fabric, High Contrast Matte White 50" x 67" - 84" diag. 1 $155.00
70053 Fabric, Matte White 60" x 80" - 100" diag. 1 $213.00
92776 Fabric, High Contrast Matte White 60" x 80" - 100" diag. 1 $230.00
70050 Fabric, Matte White 69" x 92" - 120" diag. 1 $294.00
92777 Fabric, High Contrast Matte White 69" x 92" - 120" diag. 1 $322.00
Square Format
70047 Fabric, Matte White 60" x 60" 1 $116.00
92768 Fabric, High Contrast Matte White 60" x 60" 1 $127.00
70048 Fabric, Matte White 70" x 70" 1 $142.00
92769 Fabric, High Contrast Matte White 70" x 70" 1 $155.00
70049 Fabric, Matte White 84" x 84" 1 $230.00
92770 Fabric, High Contrast Matte White 84" x 84" 1 $255.00
70050 Fabric, Matte White 6' x 8' 1 $294.00
92777 Fabric, High Contrast Matte White 6' x 8' 1 $322.00
90947 Fabric, Matte White 8' x 8' 1 $331.00
92772 Fabric, High Contrast Matte White 8' x 8' 1 $366.00
5 36507 Pin end plug, 2.25" 1 $2.30
6 90956 Roller assy., 2.25" diam. for 50" screens (includes #5) 1 $72.50
90957 Roller assy., 2.25" diam. for 60" and 72" diag. screens (includes #5) 1 $76.90
90958 Roller assy., 2.25" diam. for 70", 84" diag. and 77" diag. screens (includes #5) 1 $85.70
90959 Roller assy., 2.25" diam. for 84", 96" diag., 100" diag. and 92" diag. screens (includes #5) 1 $94.40
90960 Roller assy., 2.25" diam. for 8', 120" diag. and 106" diag. screens (includes #5) 1 $105.00
7 46083 Flange bearing 1 $0.29
8 89590 Roller bracket assy., pin end (prior to 9/04/07) (not shown) 1 $12.70
93518 Roller bracket assy., pin end (includes #7) 1 $12.70
9 34137 Bolt for roller brackets 4 $0.72
10 23104 Hex nut for roller brackets 4 $0.32
11 88770 Hanger bracket 1 $25.00
12 12388 Screw for hanger bracket, White (for screens with standard white case) 2 $0.20
12389 Screw for hanger bracket, Black (for screens with black case) 2 $0.75
