33
DL–0621 (Rev. 5) 07.21
© 2021 Legrand AV Inc.
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
16 Aluminum white case
HDTV (16:9) Format
37422 Aluminum white case for 220"HD diag. screens 1 $6,000.00
37423 Aluminum white case for 247" diag. screens 1 $7,500.00
37424 Aluminum white case for 275" diag. screens 1 $7,500.00
37425 Aluminum white case for 298" diag. screens 1 $7,500.00
Wide (16:10) Format
70664 Aluminum white case for 208" diag. screens 1 $6,000.00
70814 Aluminum white case for 226" diag. screens 1 $6,000.00
Video (4:3) Format
37418 Aluminum white case for 210" diag. screens 1 $6,000.00
37420 Aluminum white case for 240" diag. screens 1 $6,000.00
37419 Aluminum white case for 220" diag. screens 1 $6,000.00
37421 Aluminum white case for 270" diag. screens 1 $7,500.00
17 35882 Hanger bracket 5-7 $10.25
18 38040 Bolt for hanger brackets 10-14 $1.70
38041 Nut for hanger brackets 10-14 $0.49
44842 Washer for hanger brackets 10-14 $0.35
19 Motor assemblies for 1.563 roller ( not shown)
21268
Motor assy., 120v for 10'6 x 14', 14' x 14', 12' x 16', 210" diag., 220" diag., 240" diag., 220" HD diag., 208" diag.
and 226" diag. screens
1 $243.00
21251 Motor assy., 120v for 270" diag. and 247" diag. screens 1 $243.00
21252 Motor assy., 120v for 275" diag. and 298" diag. screens 1 $243.00
21269
Motor assy., 240v for 10'6 x 14', 14' x 14', 12' x 16', 210" diag., 220" diag., 240" diag., 220" HD diag., 208" diag.
and 226" diag. screens
1 $243.00
21253 Motor assy., 240v for 270" diag. and 247" diag. screens 1 $243.00
21254 Motor assy., 240v for 275" diag. and 298" diag. screens 1 $243.00
99621 Drive wheel 1 $2.15
20 35914 Junction box 1 $13.25
35915 Junction box cover 1 $2.30
21 94082 Screws to attach the junction box cover 2 $0.16
22 35896 PCB and housing assy., 120v 1 $378.00
32752 PCB and housing assy., 240v 1 $378.00
23 35883 Motor end cap assy. 1 $48.70
24 39875RPL Motor assy., 120v for 5.75" roller 1 $585.00
32767RPL Motor assy., 230v for 5.75" roller 1 $585.00
25 35916 Roller bracket, motor end 1 $20.85
26 37866 Motor bracket 1 $7.00
27 38739 Bolt to attach the motor bracket to the roller bracket 2 $0.75
44753 Nut to attach the motor bracket to the roller bracket 2 $0.27
28 40975 3-Button switch-LVC, white (not shown) 1 $101.00
