48 Advantage
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
33470 Fabric and roller assy., Matte White 8' x 10' 1 $1,007.00
33471 Fabric and roller assy., High Contrast Matte White 8' x 10' 1 $1,047.00
33475 Fabric and roller assy., Matte White 10' x 10' 1 $961.00
33478 Fabric and roller assy., Matte White 9' x 12' 1 $1,105.00
37160 Fabric and roller assy., Matte White 12' x 12' 1 $2,112.00
5 Roller assemblies. Add an "M" to the roller assy. part number for screens with built in SCB-200
58532 Roller assy., 3" diam. for 60" and 72" diag. screens 1 $50.60
58533 Roller assy., 3" diam. for 70" and 84" diag. screens 1 $52.80
58534 Roller assy., 3" diam. for 84", 96" diag. and 100" diag. screens 1 $99.00
97241 Roller assy., 3.25" diam. for 92" diag. and 94" diag. screens 1 $159.00
58535 Roller assy., 3" diam. for 8' and 120" diag. screens 1 $111.00
97242 Roller assy., 3.25" diam. for 106" diag. and 109" diag. screens 1 $176.00
99527 Roller assy., 3.25" diam. for 110" diag. and 113" diag. screens 1 $184.00
58536 Roller assy., 3" diam. for 9' screens 1 $116.00
97243 Roller assy., 3.25" diam. for 119" diag. and 123" diag. screens 1 $193.00
34914 Roller assy., 3.25" diam. for 130" diag. screens 1 $160.00
58537 Roller assy., 3.25" diam. for 10', 150" diag., 133" diag. and 137" diag. screens 1 $206.00
58538 Roller assy., 3.25" diam. for 12', 180" diag., 159" diag. and 164" diag. screens 1 $240.00
82440 Roller assy., 3.25" diam. for 200" diag., 184" diag. and 189" diag. screens 1 $237.00
6 84478 Bracket assy., pin end (prior to 4/01/07) 1 $14.00
34164 Bracket assy., pin end kit for standard and LVC screens (4/01/07 to 7/22/07) 1 $14.00
34170LGW Bracket, pin end for SCB-100/200 screens (4/01/07 to 7/22/07) 1 $14.00
23103 Bracket, pin end 1 $14.00
7 46394 Flanged bearing 1 $0.53
8 23105 Bolt for roller brackets 8 $0.47
9 23101 Grommet for roller brackets 8 $1.95
10 23104 Hex nut for roller brackets 8 $0.32
11a
Door for standard screens with LVC. See 11b for screens with SCB-100 / SCB-200 or screens with LVC built
prior to 7/01/06.
84131 White door for 60" and 72" diag. standard and LVC screens 1 $85.70
84237 White door for 70" and 84" diag. standard and LVC screens 1 $87.90
34399 White door for 84", 96" diag., 100" diag., 92" diag. and 94" diag. standard and LVC screens 1 $99.20
84239 White door for 8', 120" diag., 106" diag. and 109" diag. standard and LVC screens 1 $105.00
84554 White door for 110" diag. and 113" diag. standard and LVC screens 1 $105.00
84240 White door for 9', 119" diag. and 123" diag. standard and LVC screens 1 $107.00
34934 White door for 130" diag. standard and LVC screens 1 $109.00
84242 White door for 10', 150" diag., 133" diag. and 137" diag. standard and LVC screens 1 $109.00
36381 White door for 12', 180" diag., 159" diag. and 164" diag. standard and LVC screens 1 $116.00
84567 White door for 200" diag., 184" diag. and 189" diag. standard and LVC screens 1 $119.00
11b Order the following door for LVC screens prior to 7/01/06.
84131 White door for 50" SCB-100/200 screens 1 $85.70
84237 White door for 60" and 72" diag. SCB-100/200 screens 1 $87.90
91721 White door for 70" and 84" diag. SCB-100/200 screens 1 $90.00
91722 White door for 84", 96" diag., 100" diag., 92" diag. and 94" diag. SCB-100/200 screens 1 $101.00
84556 White door for 8', 120" diag., 106" diag. and 109" diag. SCB-100/200 screens 1 $107.00
84557 White door for 110" diag. and 113" diag. SCB-100/200 screens 1 $107.00
91723 White door for 9', 119" diag. and 123" diag. SCB-100/200 screens 1 $109.00
84560 White door for 130" diag. SCB-100/200 screens 1 $109.00
