225
DL–0691 (Rev. 2) 07.21
© 2021 Legrand AV Inc.
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 89179 Short hanger for wing arms 2 $7.60
2 89178 Long hanger for valance bar, wing bar and skirt bar sliders 2 $12.55
3 90982 Rivnut spacer - used between frame and leg assy. 8-20 $0.64
4 78454 Rivnut, short steel 5/16 - 18 - used on leg assy. 4 $2.15
5 47473 Rivnut, steel 5/16 - 18 long - used to screw speedy cranks to frames varies $2.80
6 47441 Snap stud - mounts to frame to snap fabric onto frame varies $0.59
7 44829 Washer, spring .563OD x .195ID x .008T - used on leg brace assembly and corner brace assembly 3 $0.23
8 47351 Washer, flat .437OD x .203ID x .031T - used to attach foot to frame 2-6 $0.23
9 93448 spacer - used as shoulder for #14 rivet 4 $1.50
10 44830 Rivet, .187 x 1.375" long - used to mount hinge/latch assy. to frame varies $0.26
11 88801 Rivet, .187 x 1.500" long - used to attach the foot to frame 2-6 $0.70
12 88802 Rivet, .186 x 1.609" long - used to attach rubber foot and latches to leg assy. 8 $0.39
13 91777 Rivet, .184 x 2.93" long - used to mount the latch assy. to leg assy. 12 $0.90
14 33431 Rivet, .186 x 3.78" long - used to attach the skirt bar slider to the frame ( used with #9) 4 $1.35
15 91949 Rivet, .250 x 2.968 long - used to attach hinge/latch assy. to leg assy. 2-5 $1.27
16 33143 Rivet, .250 x 3.650 long - used to attach blue latch on hinge/latch assy. 12 $1.35
17 88901 Rivet, shoulder .238 x 1.504" long - mounts to frame to hook Dressup hardware 6 $0.47
18 37317 Hinge/latch assy. casting - used on the frame 2-8 $47.70
19 37318 Hinge/latch assy. extension casting - used on frame of 13' x 17' and over 6/8 $67.60
20 35132 Corner connecting tube - used on the frame 4 $23.95
21 33147 Plastic plug, 1.25" x 3.50" 4 $0.78
22 48570 Pop rivet - used to mount hinge/latch assy. casting to the frame 4 $0.32
23 ----- Skirt bar slider for adjustable skirt bar only - No longer available, discontinued 2 -----
24 88599 Plastic plug, 1.25" square 8 $0.53
25 47353 Rubber foot - used on leg assy. and dress up kit hardware 6 $0.47
26 99148 Left latch assy. - used on leg assy. Under 18FT 2-5 $43.40
99148-LG Left latch assy. - used on leg assy. 18FT and over 2-5 $43.40
27 99150 Right latch assy. - used on leg assy. Under 18FT 2-5 $43.40
99150-LG Right latch assy. - used on leg assy. 18FT and over 2-5 $43.40
28 94679 Corner lock assy. - used on frames 4 $27.00
29 58659 Right corner brace assembly - used on leg assy. 2 $14.90
30 58660 Left corner brace assembly - usded on leg assy. 2 $14.90
31 89196 Speedy crank, 2.96" 1 $7.50
32 93488 Long speedy crank, 3.75" varies $7.50
33 91029 Corner hinge plate - used on leg assy. 4 $2.00
34 ----- Skirt bar steadyrest assembly - No longer available, discontinued 1 -----
35 47489 Light socket - used for all fabric snaps except corners varies $0.37
47490 Heavy socket - used for dress up kits and corners, black varies $0.37
36 47491 Black cap - used on three sides of fabrics and dress up kits varies $0.37
37 47492 Double cap - used at the bottom of all fabrics varies $0.37
38 76781 Snap tool - used to replace both types of snaps 1 $287.00
