DL–0663 (Rev. 9) 07.21
© 2021 Legrand AV Inc.
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
34913
Case, white for 130" diag. screens
1
$76.90
78306
Case, white for 10', 150" diag., 133" diag. and 137" diag. screens
1
$78.90
78333
Case, white for 9'x12', 180" diag., 159" diag. and 164" diag. screens
1
$92.10
11
93566
Enclosure, motor end
1
$9.15
12
25736
Screw for motor end cap
5
$0.27
13
37507
Motor end cap, white
1
$16.00
14
89464
Screw for cover plate
1
$0.37
15
50846
Enclosure screw, #10-32
2
$0.16
16
38043
Cover plate, motor end cap
1
$2.30
17
87026
Roller bracket, motor end
1
$9.15
18
37510KIT
Motor assy., 120v for 3" roller
1
$390.00
38888KIT
Motor assy., 120v for 3" roller with built-in LVC or VPI
1
$487.00
32260SKIT
Motor assy., 120v Silent for 3" roller
1
$487.00
38888LSKIT Motor assy., 120v Silent for 3" roller with built-in LVC or VPI
1
$585.00
37511KIT
Motor assy., 120v for 3.25" roller
1
$390.00
38889KIT
Motor assy., 120v for 3.25" roller with built-in LVC or VPI
1
$487.00
32262SKIT
Motor assy., 120v Silent for screens with 3.25" roller up to and including 10x10
1
$487.00
38889LSKIT Motor assy., 120v Silent with built-in LVC for screens with 3.25" roller up to and including 10x10
1
$585.00
32689KIT
Motor assy., 240v for 3" roller
1
$390.00
32638KIT
Motor assy., 240v for 3" roller with built-in LVC before 4/12/2018
1
$800.00
12148KIT
Motor assy., 240v for 3" roller with built-in LVC 4/12/2018 and after
1
$487.00
32267SKIT
Motor assy., 240v Silent for 3" roller
1
$487.00
32638LSKIT Motor assy., 240v Silent for 3" roller with built-in LVC before 6/11/2018
1
$585.00
12280KIT
Motor assy., 240v Silent for 3" roller with built-in LVC 6/11/2018 and after
1
$585.00
32690KIT
Motor assy., 240v for 3.25" roller
1
$390.00
32644KIT
Motor assy., 240v for 3.25" roller with built-in LVC before 4/12/2018
1
$800.00
12149KIT
Motor assy., 240v for 3.25" roller with built-in LVC 4/12/2018 and after
1
$487.00
32268SKIT
Motor assy., 240v Silent for screens with 3.25" roller up to and including 10x10
1
$487.00
32644LSKIT
Motor assy., 240v Silent with built-in LVC for screens with 3.25" roller up to and including 10x10 before
6/11/2018
1
$585.00
12281KIT
Motor assy., 240v Silent with built-in LVC for screens with 3.25" roller up to and including 10x10 after
6/11/2018
$585.00
94785
Drive wheel/rubber mount for screens purchased before 1/22/04 (not shown)
1
$60.00
19
97290
Hair cotter pin, 5/16" - 3/8" x 1 5/8"
1
$0.47
20
99607
ILT/LVC motor hardware kit (not shown)
1
$120.00
39021
Low Voltage Trigger, Motor VPI Kit (not shown)
1
$205.00
80575
Wall switch, 120v white (not shown)
1
$77.00
40961
Wall switch, 120v ivory (not shown)
1
$77.00
11147
Wall switch, 240v white double push putton (not shown)
1
$77.00
38463E
Wall switch, 240v white rocker (not shown)
1
$77.00
