42 Advantage (with Closure Door)
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
58535 Roller assy., 3" diam. for 8' and 120" diag. screens 1 $111.00
97242 Roller assy., 3.25" diam. for 106" diag. and 109" diag. screens 1 $176.00
99527 Roller assy., 3.25" diam. for 110" diag. and 113" diag. screens 1 $184.00
58536 Roller assy., 3" diam. for 9' screens 1 $116.00
97243 Roller assy., 3.25" diam. for 119" diag. and 123" diag. screens 1 $193.00
34914 Roller assy., 3.25" diam. for 130" diag. screens 1 $160.00
58537 Roller assy., 3.25" diam. for 10', 150" diag., 133" diag. and 137" diag. screens 1 $206.00
58538 Roller assy., 3.25" diam. for 12', 180" diag., 159" diag.and 164" diag. screens 1 $240.00
82440 Roller assy., 3.25" diam. for 200" diag., 184" diag. and 189" diag. screens 1 $237.00
17 46083 Flanged bearing 1 $0.29
18 34202WHITE Pin end bracket for 1.59" roller, white (after 10/01/07) 1 $13.80
19 70038 Motor and 1.59 roller assy., 120v 50" for 50" x 50" - 8' x 8' screens 1 $289.00
70040 Motor and 1.59 roller assy., 120v 70.75" for 110" diag. - 10' x 10' screens 1 $292.00
70042 Motor and 1.59 roller assy., 120v 84" for 12' x 12' - 200" diag. screens 1 $295.00
70038E Motor and 1.59 roller assy., 240V 50" x 50" - 8' x 8' screens 1 $289.00
70040E Motor and 1.59 roller assy., 240V 70.75" for 110" diag. - 10' x 10' screens 1 $292.00
70042E Motor and 1.59 roller assy., 240V 84" for 12' x 12' - 200" diag. Screens 1 $295.00
20 86689 Aluminum white case for 60" and 72" diag. screens 1 $512.00
86723CUT Aluminum white case for 70" and 84" diag. screens 1 $565.00
86724 Aluminum white case for 84", 96" diag., 100" diag., 92" diag. and 94" diag. screens 1 $633.00
86726 Aluminum white case for 8', 120" diag., 106" diag. and 109" diag. screens 1 $648.00
86673 Aluminum white case for 110" diag. and 113" diag. screens 1 $675.00
86675 Aluminum white case for 9', 119" diag. and 123" diag. screens 1 $654.00
34954 Aluminum white case for 130" diag. screens 1 $742.00
86728 Aluminum white case for 10', 150" diag., 133" diag. and 137" diag. screens 1 $827.00
86729 Aluminum white case for 12', 180" diag., 159" diag. and 164" diag. screens 1 $944.00
86687 Aluminum white case for 200" diag., 184" diag. and 189" diag. screens 1 $1,045.00
21 20611KIT Motor assy., 120v for standard screens with 3" rollers 1 $390.00
89046KIT Motor assy., 120v for SCB100/200 screens with 3" rollers 1 $390.00
20612KIT Motor assy., 120v for standard screens with 3.25" rollers up to and including 10' x 10' 1 $390.00
37989KIT Motor assy., 120v for standard screens over 10' wide with 3.25" rollers 1 $390.00
33154KIT Motor assy., 120v for SCB100/200 with 3.25" rollers 1 $390.00
20613KIT Motor assy., 240v for standard screens with 3" rollers 1 $390.00
31967KIT Motor assy., 240v for SCB100/200 screens with 3" rollers 1 $390.00
20614KIT Motor assy., 240v for standard screens with 3.25" rollers up to and including 10' x 10' 1 $390.00
32692KIT Motor assy., 240v for standard screens over 10' wide with 3.25" rollers 1 $390.00
32641KIT Motor assy., 240v for SCB100/200 with 3.25" rollers 1 $390.00
22 38003 Motor assy., 120v for 1.59" roller (not shown) 1 $243.00
32732 Motor assy., 240v for 1.59" roller (not shown) 1 $243.00
94785 Drive wheel/rubber mount for screens purchased before 1/22/04 (not shown) 1 $60.00
23 34201WHITE Motor end bracket for 3" and 3.25" roller, white (after 10/01/07) 1 $20.40
34189WHITE Motor end bracket for 1.59" roller, white (not shown) (after 10/01/07) 1 $20.40
24 97290 Hair cotter pin, 5/16" - 3/8" x 1 5/8" 1 $0.47
25 94693 Motor end bracket, cover white (prior to 10/01/07) 1 $9.70
34203WHITE Motor end bracket, cover white for SCB100/200 screens 1 $9.70
26 94719 Access door bracket 2 $6.10
27 72537 Screw for access door bracket (pre 8/16) 2 $0.32
10908 Screw for access door bracket (8/16 and later) 2 $0.32
