Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 89877 Right latch assy., used on frame and legs (Prior to 6/08) 5 $40.00
36234 Right hinge/latch assy., used on frame and legs 5 $11.25
2 89876 Left latch assy., used on frame and legs (Prior to 6/08) 5 $40.00
36240 Left hinge/latch assy., used on frame and legs 5 $11.25
3 47473 Rivnut, steel 5/16-18 long - used on frame for speedy cranks 10 $2.80
4 88801 Rivet, .187 x 1.500" long - used to mount corner hinge plate to frame 8 $0.70
5 88901 Rivet, shoulder .238 x 1.504" long - mounts to frame to hook Dressup hardware 10 $0.47
6 88802 Rivet, .186 x 1.609" long - used for corner hinge plate assy. 4 $0.39
7 94079 Rivet, .200 x 1.676" long - used to mount latch assy. to frame (Prior to 6/08) 40 $1.25
44830 Rivet, .187 x 1.375" long - used to mount latch assy. to frame 40 $0.26
8 44812 Spring washer - used in corner hinge plate assy., beneath corner hinge plates 10 $0.35
9 47441 Snap stud - mounts to frame to snap fabric onto frame 20 $0.59
10 47206 Rivet setting tool 1 $200.00
11 91029 Corner hinge plate - used to join frame corner 10 $2.00
12 47207 Rivnut tool 1 $184.00
13 88807 Spacer, .250OD x .194ID x 1.25" long - used in latch assy. (Prior to 6/08) 10 $1.27
14 88806 Spring - used in latch assy., beneath the blue latch (Prior to 6/08) 20 $0.70
For complete Deluxe Frame repair kit, order as follows:
89875 Fast-Fold Deluxe Frame Repair Kit (Prior to 6/08) (includes #1-14) 1 $602.00
36975 Fast-Fold Deluxe Frame Repair Kit (includes #1-12) 1 $602.00
