12 Tensioned Advantage (with Closure Door)
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
10 52703 Screw to attach hinges to doors 6/10 $0.09
11 38806 Screw to attach hinges to case 6/10 $0.32
12 34195WHITE Pin end cap, white for standard and LVC screens 1 $22.65
13 34138 Bolt for roller brackets 8 $0.47
14 23104 Hex nut for roller brackets 8 $0.32
15 46394 Flanged bearing 1 $0.53
16 34190WHITE Pin end bracket for 3.25" roller, white 1 $13.80
17 46083 Flanged bearing 1 $0.29
18 34202WHITE Pin end bracket for 1.59" roller, white 1 $13.80
19 70038
Motor and 1.59 roller assy., 120v 50" for 50" x 50", 60" x 60", 70" x 70", 72" diag., 84" diag., 100" diag., 92" diag.
and 94" diag. screens
1 $289.00
70040
Motor and 1.59 roller assy., 120v 70.75" for 84" x 84", 6' x 8', 8' x 8', 7' x 9', 9' x 9', 8' x 10', 10' x 10', 120" diag.,
150" diag., 106" diag., 110" diag., 119" diag., 133" diag., 109" diag., 113" diag., 123" diag., 130" diag. and 137" diag.
screens
1 $292.00
70042 Motor and 1.59 roller assy., 120v 84" for 9' x 12', 12' x 12', 180" diag., 159" diag. and 164" diag. screens 1 $295.00
70044 Motor and 1.59 roller assy., 120v 84" for 200" diag., 184" diag. and 189" diag. screens 1 $300.00
70038E
Motor and 1.59 roller assy., 240v 50" for 50" x 50", 60" x 60", 70" x 70", 72" diag., 84" diag., 100" diag., 92" diag.
and 94" diag. screens
1 $289.00
70040E
Motor and 1.59 roller assy., 240v 70.75" for 84" x 84", 6' x 8', 8' x 8', 7' x 9', 9' x 9', 8' x 10', 10' x 10', 120" diag.,
150" diag., 106" diag., 110" diag., 119" diag., 133" diag., 109" diag. 113" diag. 123" diag., 130" diag., and 137" diag.
screens
1 $292.00
70042E Motor and 1.59 roller assy., 240v 84" for 9' x 12', 12' x 12', 180" diag., 159" diag. and 164" diag. screens 1 $295.00
70044E Motor and 1.59 roller assy., 240v 84" for 200" diag., 184" diag. and 189" diag. screens 1 $300.00
20 Aluminum white case
HDTV (16:9) Format
86672 Aluminum white case for 92" diag. screens 1 $643.00
86674 Aluminum white case for 106" diag. screens 1 $705.00
94817 Aluminum white case for 110" diag. screens 1 $728.00
86678 Aluminum white case for 119" diag. screens 1 $775.00
86681 Aluminum white case for 133" diag. screens 1 $838.00
86685 Aluminum white case for 159" diag. screens 1 $958.00
35835 Aluminum white case for 184" diag. screens 1 $1,055.00
Wide (16:10) Format
34960 Aluminum white case for 94" diag. screens 1 $643.00
71160 Aluminum white case for 109" diag. screens 1 $705.00
34961 Aluminum white case for 113" diag. screens 1 $728.00
20688 Aluminum white case for 123" diag. screens 1 $775.00
34962 Aluminum white case for 130" diag. screens 1 $810.00
97843 Aluminum white case for 137" diag. screens 1 $838.00
34963 Aluminum white case for 164" diag. screens 1 $958.00
70941 Aluminum white case for 189" diag. screens 1 $1,055.00
Video (4:3) Format
86691 Aluminum white case for 72" diag. screens 1 $523.00
86693 Aluminum white case for 84" diag. screens 1 $576.00
86725 Aluminum white case for 100" diag. screens 1 $643.00
86727 Aluminum white case for 120" diag. screens 1 $705.00
86682 Aluminum white case for 150" diag. screens 1 $838.00
86686 Aluminum white case for 180" diag. screens 1 $958.00
86730 Aluminum white case for 200" diag. screens 1 $1,055.00
