Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
58536
Roller assy., 3" diam. for 9' screens
1
$116.00
97243
Roller assy., 3.25" diam. for 119" diag. and 123" diag. screens
1
$193.00
34914
Roller assy., 3.25" diam. for 130" diag. screens
1
$160.00
58537
Roller assy., 3.25" diam. for 10', 150" diag., 133" diag. and 137" diag. screens
1
$206.00
58538
Roller assy., 3.25" diam. for 12', 180" diag., 159" diag. and 164" diag. screens
1
$240.00
82440
Roller assy., 3.25" diam. for 200" diag., 184" diag. and 189" diag. screens
1
$237.00
6
44840
Screw for slat hook
4
$0.32
7
44710
Tinnerman nut for slat hook
2
$0.83
8
46774
Slat hook
2
$1.75
9
44880
Screw for fabric and access doors
Per size
$0.27
10
-----
Fabric door assembly - No longer available
1
-----
11
94719
Access door bracket
2
$6.10
12
44880
Screw for access door bracket
2
$0.27
13
-----
Mounting bracket - No longer available
4
-----
14
-----
Screw for mounting bracket - No longer available
12
-----
15
44785
Screw to attach access door bracket and door hanger
2
$0.16
16
94720
Access door hanger
2
$3.30
17
-----
Screw to attach access door hanger to access door - No longer available
4
-----
18
86644
Roller bracket assy., pin end
1
$11.45
19
46394
Flanged bearing
1
$0.53
20
-----
Wood box assembly - No longer available
1
-----
21
86409
Roller bracket assy., motor end
1
$11.45
22
23104
Hex nut, 1/4" - 20
4
$0.32
23
46306
Elevator bolt for roller brackets
4
$0.49
24
-----
Access door assembly - No longer available
1
-----
25
-----
Motor box assembly - No longer available
1
-----
26
83975
Door limit switch assy. (after 3/24/2008)
1
$26.50
27
-----
Metal bottom panel for electrical enclosure - No longer available
1
-----
28
-----
Junction box - No longer available
1
-----
29
91175
Junction box cover
1
$2.65
30
98774KIT
Motor assy., 120v for screens with 3" roller
1
$390.00
32265SKIT
Motor assy., 120v Silent for screens with 3" roller
1
$487.00
33159KIT
Motor assy., 120v for screens with 3.25" roller
1
$390.00
32266SKIT
Motor assy., 120v Silent for screens with 3.25" roller
1
$487.00
32718KIT
Motor assy., 240v for screens with 3" roller
1
$390.00
32273SKIT
Motor assy., 240v Silent for screens with 3" roller
1
$487.00
32691KIT
Motor assy., 240v for screens with 3.25" roller
1
$390.00
32571SKIT
Motor assy., 240v Silent for screens with 3.25" roller
1
$487.00
94785
Drive wheel/rubber mount for screens purchased before 1/22/04 (not shown)
1
$60.00
31
97290
Hair cotter pin, 5/16" - 3/8" x 1 5/8"
1
$0.47
32
80575
Wall switch, 120v white (not shown)
1
$77.00
40961
Wall switch, 120v ivory (not shown)
1
$77.00
11147
Wall switch, 240v white double push putton (not shown)
1
$77.00
38463E
Wall switch, 240v white rocker (not shown)
1
$77.00
