183 IDEA Panoramic E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1a Standard 24" marker tray. See 1b for optional full length marker trays.
28358 24" Marker Tray Assembly 1 $45.70
1b Full length markery tray by screen size.
HDTV (16:9) Format Center Panel
28375 Full length marker tray, 46" x 81.75" center panel, 46" x 144" overall viewable area 1 $130.00
28374 Full length marker tray, 46" x 81.75" center panel, 46" x 168" overall viewable area 1 $144.00
28373 Full length marker tray, 46" x 81.75" center panel, 46" x 192" overall viewable area 1 $159.00
28372 Full length marker tray, 50" x 89" center panel, 50" x 144" overall viewable area 1 $137.00
28371 Full length marker tray, 50" x 89" center panel, 50" x 168" overall viewable area 1 $151.00
28370 Full length marker tray, 50" x 89" center panel, 50" x 192" overall viewable area 1 $166.00
28369 Full length marker tray, 53" x 94.25" center panel, 53" x 144" overall viewable area 1 $137.00
28368 Full length marker tray, 53" x 94.25" center panel, 53" x 168" overall viewable area 1 $151.00
28367 Full length marker tray, 53" x 94.25" center panel, 53" x 192" overall viewable area 1 $166.00
28366 Full length marker tray, 59.5" x 106" center panel, 59.5" x 144" overall viewable area 1 $130.00
28365 Full length marker tray, 59.5" x 106" center panel, 59.5" x 168" overall viewable area 1 $144.00
28364 Full length marker tray, 59.5" x 106" center panel, 59.5" x 192" overall viewable area 1 $159.00
Wide (16:10) Format Center Panel
28390 Full length marker tray, 46" x 73.5" center panel, 46" x 144" overall viewable area 1 $130.00
28389 Full length marker tray, 46" x 73.5" center panel, 46" x 168" overall viewable area 1 $144.00
28388 Full length marker tray, 46" x 73.5" center panel, 46" x 192" overall viewable area 1 $159.00
28387 Full length marker tray, 50" x 80" center panel, 50" x 144" overall viewable area 1 $130.00
28386 Full length marker tray, 50" x 80" center panel, 50" x 168" overall viewable area 1 $144.00
28385 Full length marker tray, 50" x 80" center panel, 50" x 192" overall viewable area 1 $159.00
28384 Full length marker tray, 53" x 84.75" center panel, 53" x 144" overall viewable area 1 $137.00
28383 Full length marker tray, 53" x 84.75" center panel, 53" x 168" overall viewable area 1 $151.00
28382 Full length marker tray, 53" x 84.75" center panel, 53" x 192" overall viewable area 1 $166.00
28381 Full length marker tray, 59.5" x 95.25" center panel, 59.5" x 144" overall viewable area 1 $137.00
28380 Full length marker tray, 59.5" x 95.25" center panel, 59.5" x 168" overall viewable area 1 $151.00
28379 Full length marker tray, 59.5" x 95.25" center panel, 59.5" x 192" overall viewable area 1 $166.00
2 83658 Screw, #8 x 1/2" for Marker Tray and Lower Support L-Brackets varies $0.13
3 28276 Lower Support L-Bracket (not included on screens with full length tray) 6 $4.50
4 24211 Seam brace for 46" high viewable screens 2 $18.30
25875 Seam brace for 50" high viewable screens 2 $17.10
25874 Seam brace for 53" high viewable screens 2 $20.55
25873 Seam brace for 59.5" high viewable screens 2 $21.75
5 50902 Nut, 10-32 to attach seam brace 8 $0.13
6 Hanging Brackets (see table)
26621 18" Hanger Bracket see table $9.15
24282 28" Hanger Bracket see table $13.65
71875 44" Hanger Bracket see table $18.30
7 29043 Replacement marker, foam eraser, cleaning cloth and cleaner kit (Not Shown) 1 $43.40
