215
DL–0699 (Rev. 2) 07.21
© 2021 Legrand AV Inc.
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 45015 End cap for 3" diam. roller 2 $14.55
46951 End cap for 5" diam. roller 2 $14.55
2 89592 Mounting screws for 3" diam. roller 4 $0.20
89592 Mounting screws for 5" diam. roller 6 $0.20
3 45028 Bottom roller for 13' 6" x 18' and smaller, and 15' x 20' screens 1 $254.00
46327 Bottom roller for 18' x 18' screens 1 $371.00
46328 Bottom roller for 20' x 20' screens 1 $402.00
46331 Bottom roller for 24' screens 1 $476.00
46330 Bottom roller for 28' screens 1 $547.00
46329 Bottom roller for 30' screens 1 $584.00
4 76608 Fabric, Matte White 10' 6" x 14' 1 $1,288.00
76610 Fabric, Matte White 14' x 14' 1 $1,665.00
76614 Fabric, Matte White 12' x 16' 1 $1,568.00
76616 Fabric, Matte White 16' x 16' 1 $2,082.00
76620 Fabric, Matte White 13' 6" x 18' 1 $2,123.00
76622 Fabric, Matte White 18' x 18' 1 $2,749.00
76626 Fabric, Matte White 15' x 20' 1 $2,691.00
76628 Fabric, Matte White 20' x 20' 1 $3,363.00
46220 Fabric, Matte White 18' x 24' 1 $3,692.00
46221 Fabric, Matte White 24' x 24' 1 $2,737.00
46224 Fabric, Matte White 21' x 28' 1 $2,844.00
46225 Fabric, Matte White 28' x 28' 1 $3,841.00
46228 Fabric, Matte White 22' 6" x 30' 1 $3,060.00
46229 Fabric, Matte White 30' x 30' 1 $4,274.00
5 57364 Rope (figure at 2 x the height + the width +10' + any extra needed) per foot $0.75
6 44996 Cable clamp for rope 1 $3.75
7 23152 Turnbuckle, #15 eye and eye for 13'6" x 18" and smaller and 15' x 20' screens 3 $15.25
23152 Turnbuckle, #15 eye and eye for 18' x 18' and 20' x 20' through 22'6" x 30' screens 5 $15.25
23152 Turnbuckle, #15 eye and eye for 30' x 30' screens 7 $15.25
8 44753 Hex lock nut, 5/16 - 18 for 13'6" x 18" and smaller and 15' x 20' screens 9 $0.27
44753 Hex lock nut, 5/16 - 18 for 18' x 18' and 20' x 20' through 22'6" x 30' screens 15 $0.27
44753 Hex lock nut, 5/16 - 18 for 30' x 30' screens 21 $0.27
9 44821 Screw, cap 5/16 - 18 x 1 3/4" for 13'6" x 18' and smaller and 15' x 20' screens 9 $0.57
44821 Screw, cap 5/16 - 18 x 1 3/4" for 18' x 18' and 20' x 20' through 22'6" x 30' screens 15 $0.57
44821 Screw, cap 5/16 - 18 x 1 3/4" for 30' x 30' screens 21 $0.57
10 45011 Top tube clamp for 13'6" x 18' and smaller and 15' x 20' screens 6 $25.40
45011 Top tube clamp for 18' x 18' and 20' x 20' through 22'6" x 30' screens 10 $25.40
45011 Top tube clamp for 30' x 30' screens 14 $25.40
11 57640 Top tube assy. for 14' screens 1 $690.00
57641 Top tube assy. for 16' screens 1 $711.00
57642 Top tube assy. for 18' screens 1 $726.00
57643 Top tube assy. for 20' screens 1 $744.00
57646 Top tube assy. for 24' screens 1 $771.00
57645 Top tube assy. for 28' screens 1 $813.00
57644 Top tube assy. for 30' screens 1 $861.00
