Da-Lite 37989KIT Motor Drive Wheel Kit (120 VAC) User Manual
Page 133
133
DL–0667 (Rev. 2) 07.21
© 2021 Legrand AV Inc.
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
14
84206
Junction box cover
1
$8.00
15
84143
Motor controller, Synchronized 120v
1
$541.00
31101
Motor controller, Synchronized 240v
1
$541.00
16
84416
Junction box, 4 gang
1
$100.00
17
46430
Junction box
1
$6.95
18
95179
Junction box cover
1
$2.65
19
80890
Frame assy. for 14' screens
1
$1,057.00
80891
Frame assy. for 16' screens
1
$1,057.00
80892
Frame assy. for 18' screens
1
$1,057.00
80893
Frame assy. for 20' screens
1
$1,083.00
80894
Frame assy. for 24' screens
1
$1,083.00
80895
Frame assy. for 28' screens
1
$1,083.00
80896
Frame assy. for 30' screens
1
$1,083.00
20
84024
Outer right pulley
1
$287.00
21
84413
Cable, wire 1/8" 7/7 strand
102.67'
$2.20
22
86449
Top tube clamp assy. for 14' through 18' screens
3
$37.20
86449
Top tube clamp assy. for 20' through 24' screens
5
$37.20
86449
Top tube clamp assy. for 28' through 30' screens
7
$37.20
23
80897
Top tube assy. for 14' screens
1
$227.00
80898
Top tube assy. for 16' screens
1
$415.00
80899
Top tube assy. for 18' screens
1
$415.00
80900
Top tube assy. for 20' screens
1
$415.00
80901
Top tube assy. for 24' screens
1
$415.00
80902
Top tube assy. for 28' screens
1
$415.00
80903
Top tube assy. for 30' screens
1
$415.00
24
76608
Fabric, Matte White 10' 6" x 14'
1
$1,288.00
76610
Fabric, Matte White 14' x 14'
1
$1,665.00
76614
Fabric, Matte White 12' x 16'
1
$1,568.00
76616
Fabric, Matte White 16' x 16'
1
$2,082.00
76620
Fabric, Matte White 13' 6" x 18'
1
$2,123.00
76622
Fabric, Matte White 18' x 18'
1
$2,749.00
76626
Fabric, Matte White 15' x 20'
1
$2,691.00
76628
Fabric, Matte White 20' x 20'
1
$3,363.00
46220
Fabric, Matte White 18' x 24'
1
$3,692.00
46221
Fabric, Matte White 24' x 24'
1
$2,737.00
46224
Fabric, Matte White 21' x 28'
1
$2,844.00
46225
Fabric, Matte White 28' x 28'
1
$3,841.00
46228
Fabric, Matte White 22' 6"' x 30'
1
$3,060.00
46229
Fabric, Matte White 30' x 30'
1
$4,274.00
25
80904
Bottom roller tube assy. for 14' screens
1
$547.00
80905
Bottom roller tube assy. for 16' screens
1
$571.00
80906
Bottom roller tube assy. for 18' screens
1
$590.00
80907
Bottom roller tube assy. for 20' screens
1
$623.00
80908
Bottom roller tube assy. for 24' screens
1
$686.00
80909
Bottom roller tube assy. for 28' screens
1
$763.00
80910
Bottom roller tube assy. for 30' screens
1
$786.00
26
84021
Pulley, 2 - 1/4" for right side
1
$142.00
27
84411
Bolt, hex 1/2" x 5"
2
$1.50
28
40975
Switch, 3 button LVC white (not shown)
1
$101.00
29
29654L
Cable and pulley left side assembly (not shown) (includes 1, 7, 8, and 21)
1
$742.00
29654R
Cable and pulley right side assembly (not shown) (includes 8, 20, 21, 26)
1
$742.00
