201
DL–0683 (Rev. 3) 07.21
© 2021 Legrand AV Inc.
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
34293 Fabric, Matte White 72" x 72" 1 $152.00
37113 Fabric, High Contrast Matte White 72" x 72" 1 $167.00
76103 Fabric, Matte White 84" x 84" (Prior to 2-8-19) 1 $230.00
92802 Fabric, High Contrast Matte White 84" x 84" (Prior to 2-8-19) 1 $255.00
12238 Fabric, Matte White 84" x 84" (2-8-19 and later) 1 $230.00
12239 Fabric, High Contrast Matte White 84" x 84" (2-8-19 and later) 1 $255.00
74342 Fabric, Matte White 6' x 8' 1 $294.00
92811 Fabric, High Contrast Matte White 6' x 8' 1 $322.00
46124 Fabric, Matte White 8' x 8' (Prior to 2-8-19) 1 $331.00
92804 Fabric, High Contrast Matte White 8' x 8' (Prior to 2-8-19) 1 $366.00
12241 Fabric, Matte White 8' x 8' (2-8-19 and later) 1 $331.00
12242 Fabric, High Contrast Matte White 8' x 8' (2-8-19 and later) 1 $366.00
46125 Fabric, Matte White 7' x 9' 1 $343.00
46126 Fabric, Matte White 9' x 9' 1 $528.00
46127 Fabric, Matte White 8' x 10' 1 $395.00
46128 Fabric, Matte White 10' x 10' 1 $658.00
77294 Fabric, Matte White 9' x 12' 1 $748.00
46130 Fabric, Matte White 12' x 12' 1 $590.00
14 38244 Slat cap, black plastic 2 $0.59
15 87044 Slat for 60" and 72" diag. screens 1 $11.10
87045 Slat for 70" and 84" diag. screens 1 $13.30
33638 Slat for 72" screens 1 $13.60
87046 Slat for 84", 100" diag., 92" diag. and 94" diag. screens 1 $15.00
87047 Slat for 8', 120" diag., 106" diag. and 109" diag. screens 1 $17.10
72401 Slat for 110" diag. and 113" diag. screens 1 $17.70
45074 Slat for 9', 119" diag. and 123" diag. screens 1 $19.20
35020 Slat for 130" diag. screens 1 $19.80
45075 Slat for 10', 150" diag., 133" diag. and 137" diag. screens 1 $21.00
45076 Slat for 12', 180" diag., 159" diag. and 164" diag. screens 1 $25.60
86844 Slat for 200" diag. screens 1 $31.40
16 25735 Screw for saddle assy. 8 $0.27
17 76991 Bail frame for 50" through 96" screens 1 $3.75
93855 Pop rivet for D-ring and bail frame for 50" through 96" screens (not shown) 2 $0.50
18 45253 D-ring, black 1 $0.40
19 78259 Saddle assy. for 9', 110" diag., 119" diag., 113" diag. and 123" diag. screens 1 $29.20
78260
Saddle assy. for 10', 12', 150" diag., 180" diag., 200" diag., 133" diag., 159" diag., 130" diag., 137" diag. and 164"
diag. screens
1 $36.40
58253 Pull cord (not shown) 1 $3.75
98840 Packing for 60" screens 1 $38.90
98841 Packing for 70" screens 1 $32.00
33655 Packing for 72" screens 1 $32.40
95050 Packing for 84" screens (Prior to 2-8-19) 1 $48.50
95051 Packing for 8' screens (Prior to 2-8-19) 1 $54.60
12256 Packing for 84" screens (2-8-19 and later) 1 $48.50
12257 Packing for 8' screens (2-8-19 and later) 1 $54.60
95052 Packing for 9' screens 1 $60.50
35022 Packing for 130" diag. screens 1 $64.60
95053 Packing for 10' screens 1 $66.60
95054 Packing for 12' screens 1 $76.90
95055 Packing for 200" diag. screens 1 $85.40
