59
DL–0623 (Rev. 4) 07.21
© 2021 Legrand AV Inc.
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
13 37482 Ironing board for 14' and 210" diag. screens 1 $101.00
70911 Ironing board for 208" diag. screens 1 $103.00
37483REPL Ironing board for 16', 240" diag., 216" diag. and 222" diag. screens 1 $107.00
21935 Ironing board for 18', 265" diag. and 243" diag. screens 1 $117.00
21936 Ironing board for 20', 295" diag. and 271" diag. screens 1 $119.00
21937 Ironing board for 22' screens 1 $120.00
39202 Ironing board for 24' screens 1 $124.00
14 35907 Screws to attach the end caps 8 $0.80
15 35885 Pin end cap assy. 1 $58.50
16 35888 Door bracket assy. 2 $7.80
17 80874 Nut to attach bracket assy. 4 $0.32
18 37390 Aluminum white case for 14' and 210" diag. screens 1 $6,000.00
70755 Aluminum white case for 208" diag. screens 1 $6,000.00
37391 Aluminum white case for 16', 240" diag., 216" diag. and 222" diag. screens 1 $6,000.00
37392 Aluminum white case for 18', 265" diag. and 243" diag. screens 1 $7,500.00
37393 Aluminum white case for 20', 295" diag. and 271" diag. screens 1 $7,500.00
37394 Aluminum white case for 22' screens 1 $7,500.00
37395 Aluminum white case for 24' screens 1 $7,500.00
19 35882 Hanger bracket 5-7 $10.25
20 38040 Bolt for hanger brackets 10-14 $1.70
38041 Nut for hanger brackets 10-14 $0.49
44842 Washer for hanger brackets 10-14 $0.35
21 Motor assemblies for 1.563 roller ( not shown)
21268 Motor assy., 120v for 14', 16', 18', 210" diag., 240" diag., 265" diag., 216" diag., 243" diag. and 222" diag. Screens 1 $243.00
21251 Motor assy., 120v for 20', 295" diag. and 271" diag. screens 1 $243.00
21252 Motor assy., 120v for 22' and 24' screens 1 $243.00
21269 Motor assy., 240v for 14', 16', 18', 210" diag., 240" diag., 265" diag., 216" diag., 243" diag. and 222" diag. Screens 1 $243.00
21253 Motor assy., 240v for 20', 295" diag. and 271" diag. screens 1 $243.00
21254 Motor assy., 240v for 22' and 24' screens 1 $243.00
99621 Drive wheel 1 $2.15
22 35914 Junction box 1 $13.25
35915 Junction box cover 1 $2.30
23 94082 Screws to attach the junction box cover 2 $0.16
24 35896 PCB and housing assy., 120v 1 $378.00
32752 PCB and housing assy., 240v 1 $378.00
25 35883 Motor end cap assy. 1 $48.70
26 39875RPL Motor assy., 120v for 5.75" roller 1 $585.00
35927RPL Motor assy., 120v for 7" roller 1 $681.00
32767RPL Motor assy., 230v for 5.75" roller 1 $585.00
32740 Motor assy., 240v for 7" roller 1 $681.00
27 35916 Roller bracket, motor end for 5.75" roller 1 $20.85
35880 Roller bracket, motor end for 7" roller 1 $20.85
28 37866 Motor bracket 1 $7.00
29 38739 Bolt to attach the motor bracket to the roller bracket 1 $0.75
44753 Nut to attach the motor bracket to the roller bracket 1 $0.27
30 40975 3-Button switch-LVC, white (not shown) 1 $101.00
