203 Designer Contour Manual E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 38855 CSR and spring assy. 1 $97.30
2 12388 Screw for hanger bracket, White (for screens with standard white case) 2 $0.20
12389 Screw for hanger bracket, Black (for screens with black case) 2 $0.75
3 20715 White base for 60" and 72" diag. screens 1 $131.00
20716 White base for 70", 84" diag., and 77" diag. screens 1 $136.00
20718 White base for 84", 100" diag., and 92" diag. screens 1 $146.00
20719 White base for 8', 120" diag., and 106" diag. screens 1 $150.00
4 20720 White cover for 60" and 72" diag. screens 1 $99.20
20721 White cover for 70", 84" diag., and 77" diag. screens 1 $105.00
20723 White cover for 84", 100" diag., and 92" diag. screens 1 $116.00
20724 White cover for 8', 120" diag., and 106" diag. screens 1 $119.00
5 32847 End cap assy., white 1 $17.30
6 90483 Screw for end caps 6 $0.29
7 89571 Hanger bracket 2 $10.25
8 37312 Set screw for hanger brackets 4 $0.64
9 88770 Hanger bracket 1 $25.00
10 32566 End cap, white 1 $3.75
11 80765 Roller plug for 1 3/4" roller 1 $2.30
58353 Spring assy. for 1 3/4" roller - prior to 8-08-11 1 $28.10
12 78709 1 3/4" diam. roller for 60" screens 1 $8.50
78710 1 3/4" diam. roller for 70 screens 1 $9.20
46277 1 3/4" diam. roller for 84" screens 1 $12.20
46279 1 3/4" diam. roller for 96" screens 1 $13.60
For complete 1 3/4" roller assy. order as follows: (includes #1, 11 and 12)
32852 Camlock roller assy. for 60" and 72" diag. screens 1 $107.00
32853 Camlock roller assy. for 70", 84" diag., and 77" diag. Screens 1 $107.00
32855 Camlock roller assy. for 84" screens 1 $111.00
32856 Camlock roller assy. for 96" screens 1 $112.00
13 Screen surface
HDTV (16:9) Format
96615 Fabric, Matte White 37.5" x 67" - 77" diag. 1 $142.00
96617 Fabric, High Contrast Matte White 37.5" x 67" - 77" diag. 1 $155.00
96493 Fabric, Matte White 45" x 80" - 92" diag. 1 $213.00
96495 Fabric, High Contrast Matte White 45" x 80" - 92" diag. 1 $230.00
98262 Fabric, Matte White 45" x 80" - 92" diag. with 18" black drop 1 $237.00
98263 Fabric, High Contrast Matte White 45" x 80" - 92" diag. with 18" black drop 1 $255.00
96498 Fabric, Matte White 52" x 92" - 106" diag. 1 $294.00
96500 Fabric, High Contrast Matte White 52" x 92" - 106" diag. 1 $322.00
98265 Fabric, Matte White 52" x 92" - 106" diag. with 12" black drop 1 $309.00
98266 Fabric, High Contrast Matte White 52" x 92" - 106" diag. with 12" black drop 1 $338.00
Video (4:3) Format
96468 Fabric, Matte White 43" x 57" - 72" diag. 1 $116.00
96470 Fabric, High Contrast Matte White 43" x 57" - 72" diag. 1 $127.00
96473 Fabric, Matte White 50" x 67" - 84" diag. 1 $142.00
96475 Fabric, High Contrast Matte White 50" x 67" - 84" diag. 1 $155.00
96478 Fabric, Matte White 57" x 77" - 96" diag. 1 $213.00
96480 Fabric, High Contrast Matte White 57" x 77" - 96" diag. 1 $230.00
