Page 54
54
Advantage (with ViewShare)
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
11
34399
White door for 84", 96" diag., 100" diag., 92" diag. and 94" diag. standard and LVC screens
1
$99.20
84239
White door for 8', 106" diag. and 109" diag. standard and LVC screens
1
$105.00
84554
White door for 110" diag. and 113" diag. standard and LVC screens
1
$105.00
84240
White door for 9', 119" diag. and 123" diag. standard and LVC screens
1
$107.00
34934
White door for 130" diag. standard and LVC screens
1
$109.00
84242
White door for 10', 133" diag. and 137" diag. standard and LVC screens
1
$109.00
12
79659
Screw for door
2
$0.16
13
84225
Door bracket
2
$3.20
14
72537
Screw for door bracket (pre 8/16)
2
$0.32
10908
Screw for door bracket (8/16 and later)
2
$0.32
15
50747
Screw for universal end cap
8
$0.16
16
96336WHITE Pin end cap, white
1
$22.65
17
84230
White case for 84", 92" diag. and 94" diag. standard and LVC screens
1
$611.00
84231
White case for 8', 106" diag. and 109" diag. standard and LVC screens
1
$675.00
84533
White case for 110" diag. and 113" diag. standard and LVC screens
1
$692.00
84232
White case for 9', 119" diag. and 123" diag. standard and LVC screens
1
$742.00
34933
White case for 130" diag. standard and LVC screens
1
$763.00
84234
White case for 10', 133" diag. and 137" diag. standard and LVC screens
1
$785.00
18
24603LS
Motor end cap, white 120v for LVC screens
1
$59.30
24650LS
Motor end cap, white 240v for LVC screens
1
$59.30
96334WHITE Motor end cap, white for SCB-100/200 screens
1
$22.65
34165WHITE Motor end cap, white with internal junction box (not shown)
1
$22.65
19
99584WASH Junction box
1
$11.25
94501
Junction box, internal (not shown)
1
$11.25
20
99585WASH Junction box cover
1
$6.00
94503WHITE Junction box cover, internal (not shown)
1
$2.65
21
86809
Connector assy., 120v for LVC screens
1
$4.10
86812
Connector assy., 240v for LVC screens
1
$4.10
22
34324
PCB and base assy., 120v for SCB-100 screens
1
$579.00
32695
PCB and base assy., 240v for SCB-100 screens
1
$579.00
23
24186
Bracket, motor end
1
$20.40
24
32261SKIT
Motor assy., 120v Silent for SCB-100/200 screens with 3.25" rollers
1
$487.00
38890LSKIT Motor assy., 120v Silent for LVC and VPI screens with 3.25" rollers
1
$585.00
32269SKIT
Motor assy., 240v Silent for SCB-100/200 screens with 3.25" rollers
1
$487.00
32645LSKIT Motor assy., 240v Silent for LVC screens with 3.25" rollers before 6/11/2018
1
$585.00
12279KIT
Motor assy., 240v Silent for LVC screens with 3.25" rollers 6/11/2018 and after
1
$585.00
20614KIT
Motor assy., 240v for LVC screens with 3.25" rollers I,R,Ms
1
$390.00
25
97290
Hair cotter pin, 5/16" - 3/8" x 1 5/8"
1
$0.47
26
24609
Gender changer A/B FML to FML, black box
1
$16.00
27
28473
ViewShare camera assy. with mounting screws
1
$513.00
28
24615
Zip tie, black to attach the cable to the arm assy.
6/8
$0.58
29
24635
Arm assy., 36.75" for 92" diag. and 94" diag. screens
2
$117.00
24636
Arm assy., 40.75" for 106" diag., 110" diag. and 109" diag. screens
2
$117.00
24637
Arm assy., 44.75" for 119" diag., 113" diag. and 123" diag. screens
2
$117.00
24638
Arm assy., 48.75" for 133" diag., 130" diag. and 137" diag. screens
2
$117.00
24177
Screw, black for arm assy.
1
$1.60
24179
Nut for arm assy.
2
$0.32
24178
Washer for arm assy.
4
$0.96
