75
DL–0649 (Rev. 2) 07.21
© 2021 Legrand AV Inc.
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
14 81795 Roller assy., 3.25" diam. for 12' and 159" diag. screens 1 $175.00
33028 Roller assy., 5 3/4" diam. for 200" diag. screens 1 $560.00
81662 Roller assy., 5 3/4" diam. for 14', 210" diag. and 188" diag. screens 1 $581.00
81663 Roller assy., 5 3/4" diam. for 16', 240" diag. and 216" diag. screens 1 $625.00
81664 Roller assy., 5 3/4" diam. for 18', 265" diag. and 243" diag. screens 1 $669.00
89110 Roller assy., 7" diam. for 20', 295" diag. and 271" diag. screens 1 $889.00
89111 Roller assy., 7" diam. for 22', 325" diag. and 298" diag. screens 1 $944.00
89112 Roller assy., 7" diam. for 24', 355" diag. and 326" diag. screens 1 $1,011.00
15 37866 Motor bracket for 14'-18' screens 1 $7.00
84412 Motor bracket with spring for 15' x 20' and over screens 1 $11.90
16 93205 Roller bracket, motor end for 12'-18' screens 1 $12.70
93207 Roller bracket, motor end for 20'-24' screens 1 $13.65
17 23326 Motor assy., 120v for 12' and 200" diag. screens (includes #'s 15, 16, 18 and 19 ) 1 $585.00
70860 Motor assy., 120v for 14'-18' screens (includes #'s 15, 16, 18 and 19 ) 1 $585.00
90846RPL Motor assy., 120v for 20' and over screens 1 $681.00
23327 Motor assy., 240v for 12' and 200" diag. screens (includes #'s 15, 16, 18 and 19 ) 1 $585.00
70903 Motor assy., 240v for 14'-18' screens (includes #'s 15, 16, 18 and 19 ) 1 $585.00
82737RPL Motor assy., 240v for 20' and over screens 1 $681.00
33287 Drive wheel/rubber mount for screens purchased before 1/22/04 (not shown) 1 $40.00
18 44753 Nut for motor end roller bracket for 12'-18' screens 2 $0.27
48373 Nut for motor end roller bracket for 15' x 20' and over screens 2 $0.42
19 38739 Screw for motor end roller bracket for 12'-18' screens 2 $0.75
93543 Screw for motor end roller bracket for 15' x 20' and over screens 2 $0.39
20 81659 Junction box assy. 1 $6.40
21 81657 Junction box cover 1 $4.30
22 46354 Universal hanger bracket, front for 12' - 22' screens (not shown) 3 $13.15
46354 Universal hanger bracket, front for 24' screens (not shown) 4 $13.15
46356 Front hanger bracket for 12'-18' screens (not shown) 3 $20.40
46358 Back hanger bracket for 12'-18' screens (not shown) 3 $11.70
88786 Front hanger bracket for 22' screens (not shown) 3 $22.45
88788 Back hanger bracket for 22' screens (not shown) 3 $13.65
88786 Front hanger bracket for 24' screens (not shown) 4 $22.45
88788 Back hanger bracket for 24' screens (not shown) 4 $13.65
59159 Hardware for hanger brackets for 12' - 22' screens (not shown) 1 $4.60
39863 Hardware for hanger brackets for 24' and 355" diag. screens (not shown) 2 $4.60
Note: In the event the complete hangers and hardware are to be ordered, order as follows:
59155RPL Hangers and hardware for 12'-18' screens (not shown) 1 $92.10
89270RPL Hangers and hardware for 20'-22' screens (not shown) 1 $101.00
39862RPL Hangers and hardware for 24' and 355" diag. screens (not shown) 2 $101.00
59155 Hangers and hardware for 12'-18' screens (not shown) 1 $92.10
89270 Hangers and hardware for 20'-22' screens (not shown) 1 $101.00
39862 Hangers and hardware for 24' and 355" diag. screens (not shown) 2 $101.00
23 80575 Wall switch, 120v white (not shown) 1 $77.00
40961 Wall switch, 120v ivory (not shown) 1 $77.00
11147 Wall switch, 240v white double push putton (not shown) 1 $77.00
38463E Wall switch, 240v white rocker (not shown) 1 $77.00
