187 Advantage Manual with CSR E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 82998 Screw for CSR assy. for 3" roller 3 $0.16
2 99473 CSR assy. for 3" roller - See note #1 1 $263.00
79090 CSR assy. for 3" roller - See note #2 1 $271.00
93450 CSR assy. for 10' x 10', 9' x 12', 12' x 12', 180" diag. and 200" diag. screens - See note #3 1 $271.00
3 34138 Bolt, square for roller bracket 4 $0.47
4 23104 Nut for roller bracket 4 $0.32
5 13278 Roller Bracket Assy 1 3/4" roller - after 1/27/2020 (includes CSR adjustment components) 1 $58.00
34188WHITE Roller bracket, CSR for 3" roller 1 $14.35
6 84131 White door for 60" and 72" diag. screens 1 $85.70
84237 White door for 70" and 84" diag. screens 1 $87.90
34399 White door for 84", 96" diag., 100" diag., 92" diag. and 94" diag. screens 1 $99.20
84239 White door for 8', 120" diag., 106" diag. and 109" diag. screens 1 $105.00
84554 White door for 110" diag. and 113" diag. screens 1 $105.00
84240 White door for 9', 119" diag. and 123" diag. screens 1 $107.00
34934 White door for 130" diag. screens 1 $109.00
84242 White door for 10', 150" diag., 133" diag. and 137" diag. screens 1 $109.00
36381 White door for 12', 180" diag., 159" diag. and 164" diag. screens 1 $116.00
84567 White door for 200" diag. screens 1 $119.00
7 84225 Door bracket 2 $3.20
8 72537 Screw for door bracket (pre 8/16) 2 $0.32
10908 Screw for door bracket (8/16 and later) 2 $0.32
9 79659 Screw for door 2 $0.16
10 50747 Screw for universal end cap 8 $0.16
11 96336WHITE Universal end cap, white 2 $22.65
12 84130 White case for 60" and 72" diag. screens 1 $488.00
84229 White case for 70" and 84" diag. screens 1 $544.00
84230 White case for 84", 96" diag., 100" diag., 92" diag. and 94" diag. screens 1 $611.00
84231 White case for 8', 120" diag., 106" diag. and 109" diag. screens 1 $675.00
84533 White case for 110" diag. and 113" diag. screens 1 $692.00
84232 White case for 9', 119" diag. and 123" diag. screens 1 $742.00
34933 White case for 130" diag. screens 1 $763.00
84234 White case for 10', 150" diag., 133" diag. and 137" diag. screens 1 $785.00
36380 White case for 12', 180" diag., 159" diag. and 164" diag. screens 1 $868.00
84546 White case for 200" diag. screens 1 $956.00
13 82998 Screw for spring assy. for 3" roller 3 $0.16
80765 Roller Plug,Pin End 1-3/4 Poly fir 1 3/4" roller $2.30
14 3" Roller assemblies include #1, 2,13, and 16. 1 3/4" Roller assy include #13,16
85865 3" roller assy. for 60" and 72" diag. screens - Before 1/27/2020 1 $404.00
32852 1 3/4" roller assy. for 60" and 72" diag. screens - After 1/27/2020 1 $107.00
85866 3" roller assy. for 70" and 84" diag. screens- Before 1/27/2020 1 $418.00
32853 1 3/4" roller assy. for 70" and 84" diag. screens - After 1/27/2020 1 $107.00
80185 3 "Roller assy. for 84", 100" diag., 92" diag. and 94" diag. screens - Before 1/27/2020 1 $421.00
32855 1 3/4" Roller assy. for 84", 100" diag., 92" diag. and 94" diag. screens - After 1/27/2020 1 $111.00
37509 3" Roller assy. for 106" diag. and 109" diag. screens - Before 1/27/2020 1 $423.00
39377 1 3/4" Roller assy. for 106" diag. and 109" diag. screens - After 1/27/2020 1 $112.00
80186 3 " Roller assy. for 8' and 120" diag. Screens - Before 1/27/2020 1 $423.00
39377 1 3/4" Roller assy. for 106" diag. and 109" diag. screens - After 1/27/2020 1 $112.00
