211 Model B E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 80762 Roller plug for 1 3/8" roller for 72" or smaller screens 1 $1.75
80765 Roller plug for 1 3/4" roller for 96" diag., 84" and 96" screens 1 $2.30
2 80736 Pin end cap for 72" or smaller screens, white plastic 1 $6.40
80740 Pin end cap for 96" diag., 84" and 96" screens, white plastic 1 $6.40
3 45592 Case for 60" screens, white 1 $16.55
45597 Case for 70" screens, white 1 $18.55
34139WHITE Case for 72" screens, white 1 $19.65
91992 Case for 96" diag. screens, white 1 $25.90
45493 Case for 84" screens, white 1 $27.10
45497 Case for 96" screens, white 1 $28.10
4 87387 Screw for end caps, white 6 $0.26
5 81697 D-Ring 2 $1.65
6 80477 Spring end cap for 72" or smaller screens, white plastic 1 $6.40
80743 Spring end cap for 96" diag., 84" and 96" screens, white plastic 1 $6.40
7 93493 Spring assy. for 1 3/8" roller for 72" or smaller screens 1 $13.80
93495 Spring assy. for 1 3/4" roller for 96" diag., 84" and 96" screens 1 $28.10
8a Roller only. See 8b for roller assembly.
45313 1 3/8" diam. roller for 60" screens 1 $8.60
45317 1 3/8" diam. roller for 70" screens 1 $9.40
34140WASH 1 3/8" diam. roller for 72" screens 1 $11.20
46277 1 3/4" diam. roller for 84" screens 1 $12.20
46279 1 3/4" diam. roller for 96" screens 1 $13.60
8b For complete roller assy., order as follows: (includes #1, 7 and 8)
93953 Camlock roller assy. for 60" screens 1 $22.05
93955 Camlock roller assy. for 70" screens 1 $23.70
34141 Camlock roller assy. for 72" screens 1 $25.70
93961 Camlock roller assy. for 84" screens 1 $41.90
93962 Camlock roller assy. for 96" screens 1 $42.80
9 Screen surface
HDTV (16:9) Format
93312 Fabric, Matte White 37.5" x 67" - 77" diag. 1 $142.00
93212 Fabric, High Contrast Matte White 37.5" x 67" - 77" diag. 1 $155.00
86227 Fabric, Matte White 45" x 80" - 92" diag. 1 $213.00
92741 Fabric, High Contrast Matte White 45" x 80" - 92" diag. 1 $230.00
98268 Fabric, Matte White 45" x 80" - 92" diag. with 18" black drop 1 $237.00
98269 Fabric, High Contrast Matte White 45" x 80" - 92" diag. with 18" black drop 1 $255.00
78945 Fabric, Matte White 52" x 92" - 106" diag. 1 $294.00
92742 Fabric, High Contrast Matte White 52" x 92" - 106" diag. 1 $322.00
98271 Fabric, Matte White 52" x 92" - 106" diag. with 12" black drop 1 $309.00
98272 Fabric, High Contrast Matte White 52" x 92" - 106" diag. with 12" black drop 1 $338.00
Wide (16:10) Format
35804 Fabric, Matte White 50" x 80" - 94" diag. 1 $213.00
35805 Fabric, High Contrast Matte White 50" x 80" - 94" diag. 1 $213.00
35808 Fabric, Matte White 57 1/2" x 92" - 109" diag. 1 $294.00
35809 Fabric, High Contrast Matte White 57 1/2" x 92" - 109" diag. 1 $322.00
