237
DL–0697 (Rev. 2) 07.21
© 2021 Legrand AV Inc.
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
4 75019PC Black case for 8' and 120" diag. screens 1 $92.00
75020PC Black case for 9' screens 1 $98.00
75021PC Black case for 10' and 150" diag. screens 1 $103.00
75022PC Black case for 12' and 180" diag. screens 1 $120.00
93900 Carpeted black case for 8' and 120" diag. screens 1 $310.00
93901 Carpeted black case for 9' screens 1 $390.00
89091 Carpeted black case for 10' and 150" diag. screens 1 $412.00
89092 Carpeted black case for 12' and 180" diag. screens 1 $426.00
5 37245BLACK Spring end cap, black 1 $5.85
6 Roller assemblies include #1 and 11
57686 Roller assy. for 8' and 120" diag. Screens 1 $160.00
57687 Roller assy. for 9' screens 1 $163.00
57688 Roller assy. for 10' and 150" diag. Screens 1 $166.00
57685 Roller assy. for 12' and 180" diag. Screens 1 $172.00
7 44726 Screw for dog 1 $0.29
8 98223 Pawl (dog) 1 $1.50
9 57705 Plug and spear assy. (includes #7 and 8) 1 $31.50
10 45118 Plastic anchor for spring assy. 1 $2.65
11 57706 Spring assy. (includes #9 and 10) 1 $101.00
12 Screen surface
Video (4:3) Format
38232 Fabric, Matte White 69" x 92" - 120" diag. 1 $294.00
38235 Fabric, Matte White 87" x 116" - 150" diag. 1 $395.00
38236 Fabric, Matte White 105" x 140" - 180" diag. 1 $748.00
Square Format
38232 Fabric, Matte White 6' x 8' 1 $294.00
46124 Fabric, Matte White 8' x 8' 1 $331.00
38233 Fabric, Matte White 7' x 9' 1 $343.00
46126 Fabric, Matte White 9' x 9' 1 $528.00
38234 Fabric, Matte White 8' x 10' 1 $395.00
46128 Fabric, Matte White 10' x 10' 1 $658.00
38236 Fabric, Matte White 9' x 12' 1 $748.00
46130 Fabric, Matte White 12' x 12' 1 $590.00
13 38244 Slat cap, black plastic 2 $0.59
14 87047 Slat for 8' and 120" diag. screens 1 $17.10
45074 Slat for 9' screens 1 $19.20
45075 Slat for 10' and 150" diag. screens 1 $21.00
45076 Slat for 12' and 180" diag. screens 1 $25.60
15 48563 Pop rivet for saddle assy. and extensions 12 $0.32
16 78259 Saddle assy. for 8' and 9' screens 1 $29.20
78260 Saddle assy. for 10' and 12' screens 1 $36.40
17 78588 Saddle extension for 8' and 120" diag. screens 2 $7.95
78589 Saddle extension for 9' screens 2 $9.15
78517 Saddle extension for 10' and 150" diag. screens 2 $10.25
78518 Saddle extension for 12' and 180" diag. screens 2 $12.55
95051 Packing for 8' screens 1 $54.60
95052 Packing for 9' screens 1 $60.50
95053 Packing for 10' screens 1 $66.60
95054 Packing for 12' screens 1 $76.90
