25 Tensioned Advantage (with ViewShare)
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 44839 Screw for slat cap assy. 4 $0.27
2 24613 Slat cap assy. (includes #1) 2 $9.15
3 94680 Tab pre 5-16 14-40 $0.37
10685 Tab 5-16 and later $0.37
4 75658
Line, chalk and mason black (per foot). Figure one side at approximately height of fabric + 2' + any extra
needed
Per size $0.23
5
Fabric and roller assemblies include #1, 2, 3, 4, 23, 24, 27, 28, 29, 30, 31, 32, and 35. Add an "M" to the fabric
and roller part number for screens with built in SCB-200
HDTV (16:9) Format
24002FLS Motorized, fabric and roller, Retrofit, HD Progressive 0.9 45" x 80" - 92" diag. 1 $6,462.00
24003FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 45" x 80" - 92" diag. 1 $6,462.00
24008FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 Contrast 45" x 80" - 92" diag. 1 $6,462.00
24725FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.3 45" x 80" - 92" diag. 1 $6,462.00
24004FLS Motorized, fabric and roller, Retrofit, Da-Mat 45" x 80" - 92" diag. 1 $5,783.00
24009FLS Motorized, fabric and roller, Retrofit, HD Progressive 0.9 52" x 92" - 106" diag. 1 $6,872.00
24010FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 52" x 92" - 106" diag. 1 $6,872.00
24015FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 Contrast 52" x 92" - 106" diag. 1 $6,872.00
24726FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.3 52" x 92" - 106" diag. 1 $6,872.00
24011FLS Motorized, fabric and roller, Retrofit, Da-Mat 52" x 92" - 106" diag. 1 $6,121.00
24016FLS Motorized, fabric and roller, Retrofit, HD Progressive 0.9 54" x 96" - 110" diag. 1 $7,011.00
24017FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 54" x 96" - 110" diag. 1 $7,011.00
24022FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 Contrast 54" x 96" - 110" diag. 1 $7,011.00
24727FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.3 54" x 96" - 110" diag. 1 $7,011.00
24018FLS Motorized, fabric and roller, Retrofit, Da-Mat 54" x 96" - 110" diag. 1 $6,238.00
24023FLS Motorized, fabric and roller, Retrofit, HD Progressive 0.9 58" x 104" - 119" diag. 1 $7,352.00
24024FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 58" x 104" - 119" diag. 1 $7,352.00
24029FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 Contrast 58" x 104" - 119" diag. 1 $7,352.00
24728FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.3 58" x 104" - 119" diag. 1 $7,352.00
24025FLS Motorized, fabric and roller, Retrofit, Da-Mat 58" x 104" - 119" diag. 1 $6,515.00
24030FLS Motorized, fabric and roller, Retrofit, HD Progressive 0.9 65" x 116" - 133" diag. 1 $7,823.00
24031FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 65" x 116" - 133" diag. 1 $7,823.00
24036FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 Contrast 65" x 116" - 133" diag. 1 $7,823.00
24729FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.3 65" x 116" - 133" diag. 1 $7,823.00
24032FLS Motorized, fabric and roller, Retrofit, Da-Mat 65" x 116" - 133" diag. 1 $6,905.00
Wide (16:10) Format
24037FLS Motorized, fabric and roller, Retrofit, HD Progressive 0.9 50" x 80" - 94" diag. 1 $6,462.00
24038FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 50" x 80" - 94" diag. 1 $6,462.00
24043FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 Contrast 50" x 80" - 94" diag. 1 $6,462.00
24730FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.3 50" x 80" - 94" diag. 1 $6,462.00
24039FLS Motorized, fabric and roller, Retrofit, Da-Mat 50" x 80" - 94" diag. 1 $5,783.00
24044FLS Motorized, fabric and roller, Retrofit, HD Progressive 0.9 57 1/2" x 92" - 109" diag. 1 $6,880.00
24045FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 57 1/2" x 92" - 109" diag. 1 $6,880.00
24051FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 Contrast 57 1/2" x 92" - 109" diag. 1 $7,011.00
24731FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.3 57 1/2" x 92" - 109" diag. 1 $6,880.00
24046FLS Motorized, fabric and roller, Retrofit, Da-Mat 57 1/2" x 92" - 109" diag. 1 $6,128.00
24051FLS Motorized, fabric and roller, Retrofit, HD Progressive 0.9 60" x 96" - 113" diag. 1 $7,011.00
24052FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 60" x 96" - 113" diag. 1 $7,011.00
24057FLS Motorized, fabric and roller, Retrofit, HD Progressive 1.1 Contrast 60" x 96" - 113" diag. 1 $7,011.00
