Tensioned Executive Electrol
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
80598
Fabric and roller assy., Da-Mat 65" x 116" - 133" diag.
1
$1,381.00
86447
Fabric and roller assy., Da-Tex 65" x 116" - 133" diag.
1
$2,119.00
80601
Fabric and roller assy., Da-Mat 78" x 139" - 159" diag.
1
$1,457.00
86448
Fabric and roller assy., Da-Tex 78" x 139" - 159" diag.
1
$2,231.00
6
83501
Screw for roller brackets
8
$0.60
7
44810
Screw for bumper bracket assy.
4
$0.42
8
80874
Nut for bumper bracket assy.
4
$0.32
9
44880
Screw for access door bracket and to attach hinge to case
2/brkt
$0.27
10
46645
Hanging bar
4
$31.30
-----
Screw for hanging bar (not shown) - No longer available
12
-----
11
87058
Screw for door bumper bracket
4
$0.27
12
46643
Door bumper bracket
2
$3.30
13
83010
Roller bracket assy., right
1
$16.55
83017
Bearing, flange
1
$50.00
14
-----
Roller bracket assy., left - No longer available
1
-----
83017
Bearing, flange
1
$50.00
15
44711
Retaining ring
2
$0.35
16
46559
Key for lovejoy coupling
2
$1.35
17
70937
Lovejoy coupling, black for under 20' screens
1
$29.20
-----
Lovejoy coupling, blue for 20' and over screens - No longer available
1
-----
18
76257
Spider for lovejoy coupling, black for under 20' screens
1
$9.90
91635
Spider for lovejoy coupling, blue for 20' and over screens
1
$23.00
19
46669
Motor shaft, drive 1/2" diam.
1
$24.85
20
73528
Solenoid bracket
1
$111.00
21
29000
Solenoid assembly for 120v (includes 97290)
1
$129.00
68386
Solenoid assembly for 220v (includes 97290)
$210.00
87824
Solenoid pin only
1
$14.25
79107
Solenoid spring only
1
$1.50
97290
Cotter pin, hair 5/16-3/8x1-5/8
1
$0.47
44784
Washer, flat .750ODx.312IDx.062
1
$0.29
22
73526
Clutch plate assy.
1
$18.15
46559
Key for clutch plate assy.
1
$1.35
23
83967
Limit switch set
1
$117.00
24
93938
Door microswitch and bracket assy.
2
$58.20
44810
Carriage bolt for door switch bracket assy.
2
$0.42
80874
Hex nut for door switch bracket assy.
1
$0.32
25
46648
Door stop bracket
2
$6.70
26
44810
Carriage bolt for door stop bracket
2
$0.42
80874
Hex nut for door stop bracket
2
$0.32
27
46617
Lever arm
2
$3.75
46620
Pin for lever arm
6
$2.65
47352
Washer for lever arm
2
$0.35
44813
Retaining ring for lever arm
1
$0.32
28
46615
Lever mounting bracket
2
$7.95
29
44779
Screw for mounting bracket
1
$0.27
30
79678
Lovejoy coupling retainer
2
$2.80
31
72537
Screws for lovejoy coupling retainer
1
$0.32
32
-----
Junction box - No longer available
1
-----
33
91175
Junction box cover
1
$2.65
