239
DL–0698 (Rev. 2) 07.21
© 2021 Legrand AV Inc.
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 73294 Center tube handle 1 $68.10
2 73295 Top tube handle 1 $68.10
3 44740 Screw for center and top tube handles 2 $0.18
4 44746 Screw for gooseneck 1 $0.35
5 73296 Gooseneck assy. 1 $61.60
6 57702 Top tube assy. (includes #2, 3, 4, 5, and 7) 1 $184.00
7 57699 Spring button assy. 3 $5.60
8 57703 Center tube assy. (includes #1, 3, and 7) 1 $129.00
9 57704 Bottom tube assy. 1 $65.10
For complete tube assy., order as follows: (includes #1-9)
57697 Tube assembly 1 $378.00
10 44700 Thumb screw, 1/4 - 20 x 1/2" 5 $0.91
11 82888 Plug, 1 1/2" Black 4 $0.70
12 57701 End bracket assy., (includes #10) 2 $68.40
78140 End bracket assy. for carpeted Floor Model C (includes #10) 2 $68.40
13 57700 Center bracket assy. (includes #7 and 10) 1 $216.00
14 45092 Support tube, 1 1/2" diameter x 60" 2 $21.35
89848 Packing for Floor Model C Stand 1 $30.00
