110 Tensioned Cosmopolitan
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
10 White Case
HDTV (16:9) Format
11047 White case for 92" diag. screens 1 $76.90
11024 White case for 106" diag. screens 1 $83.40
95294 White case for 110" diag. screens 1 $85.70
78837 White case for 119" diag. screens 1 $92.10
11034 White case for 133" diag. screens 1 $96.70
97789WHITE White case for 159" diag. screens 1 $101.00
Wide (16:10) Format
11048 White case for 94" diag. screens 1 $76.90
11025 White case for 109" diag. screens 1 $83.40
11026 White case for 113" diag. screens 1 $85.70
11029 White case for 123" diag. screens 1 $92.10
11031 White case for 130" diag. screens 1 $92.10
11035 White case for 137" diag. screens 1 $96.70
11039 White case for 164" diag. screens 1 $101.00
Video (4:3) Format
11041 White case for 72" diag. screens 1 $61.60
11044 White case for 84" diag. screens 1 $65.80
11049 White case for 100" diag. screens 1 $76.90
77505 White case for 120" diag. screens 1 $83.40
77506 White case for 150" diag. screens 1 $96.70
11 93566 Enclosure, motor end 1 $9.15
12 25735 Screw for motor end cap 5 $0.27
13 37507 Motor end cap 1 $16.00
14 77814 Screw for cover plate 1 $0.37
15 50846 Enclosure screw, #10-32 2 $0.16
16 38043 Cover plate, motor end cap 1 $2.30
17 87026 Roller bracket, motor end 1 $9.15
18 37511KIT Motor assy., 120v for screens with 3.25" roller 1 $390.00
38889KIT Motor assy., 120v with built-in LVC for screens with 3.25" roller 1 $487.00
32262SKIT Motor assy., 120v Silent for screens with 3.25" roller up to and including 10x10 1 $487.00
38889LSKIT Motor assy., 120v Silent with built-in LVC for screens with 3.25" roller up to and including 10x10 1 $585.00
32690KIT Motor assy., 240v for screens with 3.25" roller 1 $390.00
32644KIT Motor assy., 240v with built-in LVC for screens with 3.25" roller before 4/12/2018 1 $800.00
12149KIT Motor assy., 240v with built-in LVC for screens with 3.25" roller 4/12/2018 and after 1 $487.00
32268SKIT Motor assy., 240v Silent for screens with 3.25" roller up to and including 10x10 1 $487.00
32644LSKIT
Motor assy., 240v Silent with built-in LVC for screens with 3.25" roller up to and including 10x10 before
6/11/2018
1 $585.00
12281KIT
Motor assy., 240v Silent with built-in LVC for screens with 3.25" roller up to and including 10x10 6/11/2018
and after
1 $585.00
94785 Drive wheel/rubber mount for screens purchased before 1/22/04 (not shown) 1 $60.00
97290 Hair cotter pin, 5/16" - 3/8" x 1 5/8" 1 $0.47
19 99607 ILT/LVC motor hardware kit (not shown) 1 $120.00
