Da-Lite 37989KIT Motor Drive Wheel Kit (120 VAC) User Manual
Page 152
152
DL–0671 (Rev. 2) 07.21
© 2021 Legrand AV Inc.
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
6
44726
Screw, 8-32x3/8" Phillip truss head, for corners of bezel
4
$0.29
7
71429
Screw, 10Ax3/8" Phillip sheet metal, to attach bezel to frame
Per size
$0.29
8
Bezel assembly
HDTV (16:9) Format
25604
Bezel assy for 77" diag. screens 16:9, acid etched black
1
$639.00
25607
Bezel assy for 82" diag. screens 16:9, acid etched black
1
$688.00
25610
Bezel assy for 92" diag. screens 16:9, acid etched black
1
$769.00
25613
Bezel assy for 100" diag. screens 16:9, acid etched black
1
$835.00
25616
Bezel assy for 106" diag. screens 16:9, acid etched black
1
$938.00
25619
Bezel assy for 110" diag. screens 16:9, acid etched black
1
$984.00
25622
Bezel assy for 119" diag. screens 16:9, acid etched black
1
$1,066.00
25625
Bezel assy for 133" diag. screens 16:9, acid etched black
1
$1,217.00
25628
Bezel assy for 159" diag. screens 16:9, acid etched black
1
$1,390.00
25631
Bezel assy for 193" diag. screens 16:9, acid etched black
1
$1,513.00
25634
Bezel assy for 220" diag. screens 16:9, acid etched black
1
$1,638.00
Wide (16:10) Format
25637
Bezel assy for 94" diag. screens 16:10, acid etched black
1
$769.00
25640
Bezel assy for 109" diag. screens 16:10, acid etched black
1
$938.00
25643
Bezel assy for 113" diag. screens 16:10, acid etched black
1
$984.00
25646
Bezel assy for 123" diag. screens 16:10, acid etched black
1
$1,066.00
25649
Bezel assy for 130" diag. screens 16:10, acid etched black
1
$1,141.00
25652
Bezel assy for 137" diag. screens 16:10, acid etched black
1
$1,217.00
25655
Bezel assy for 164" diag. screens 16:10, acid etched black
1
$1,390.00
25658
Bezel assy for 189" diag. screens 16:10, acid etched black
1
$1,484.00
25661
Bezel assy for 208" diag. screens 16:10, acid etched black
1
$1,575.00
25664
Bezel assy for 226" diag. screens 16:10, acid etched black
1
$1,638.00
2.35:1 Cinemascope Format
25667
Bezel assy for 96" diag. screens Cinemascope, acid etched black
1
$835.00
25670
Bezel assy for 103" diag. screens Cinemascope, acid etched black
1
$984.00
25673
Bezel assy for 115" diag. screens Cinemascope, acid etched black
1
$1,066.00
25676
Bezel assy for 125" diag. screens Cinemascope, acid etched black
1
$1,209.00
25679
Bezel assy for 133" diag. screens Cinemascope, acid etched black
1
$1,240.00
25682
Bezel assy for 138" diag. screens Cinemascope, acid etched black
1
$1,278.00
25685
Bezel assy for 148" diag. screens Cinemascope, acid etched black
1
$1,362.00
25688
Bezel assy for 166" diag. screens Cinemascope, acid etched black
1
$1,454.00
25691
Bezel assy for 199" diag. screens Cinemascope, acid etched black
1
$1,565.00
25694
Bezel assy for 208" diag. screens Cinemascope, acid etched black
1
$1,638.00
9
24558
Hanger hardware for screens under 104" in viewing width
1
$95.80
24559
Hanger hardware for screens 104" and over in viewing width
1
$162.00
10
23354
Screw for bottom frame bracket. 8-32x1/2" Fillister head screw.
1/2
$0.45
(1) Screw for screens under 104" in viewing width
(2) Screws for screens 104" and over in viewing width
11
71429
Screw to attach bottom frame bracket to bezel. 10Ax3/8" Phillip sheet metal screw.
2/4
$0.29
(2) Screws for screens under 104" in viewing width
(4) Screws for screens 104" and over in viewing width
87014
Carton - Viewing width of screen + 8-1/2"
Per foot
$2.30
