Da-Lite 37989KIT Motor Drive Wheel Kit (120 VAC) User Manual
Page 115
115
DL–0662 (Rev. 4) 07.21
© 2021 Legrand AV Inc.
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
21
84470
Connector assy., 120v
1
$7.00
86809
Connector assy., 120v with built-in LVC
1
$4.10
84482
Connector assy., 240v
1
$7.00
86812
Connector assy., 240v with built-in LVC
1
$4.10
22
89464
Screw for cover plate, white
1
$0.37
23
96305
Cover plate, motor end cap
1
$5.30
24
44799
Ground screw, #10-32 for wire cover
1
$0.32
25
99501WHITE Cover, wire
1
$2.65
26
28692BLACK Roller bracket, motor end (for screens manufactured prior to 1-05-15, it will be necessary to also replace #6)
1
$38.00
27
38845RPL
Motor assy., 120v
1
$585.00
20996RPL
Motor assy., 120v with built-in LVC
1
$681.00
32749RPL
Motor assy., 240v
1
$585.00
32625RPL
Motor assy., 240v with built-in LVC
1
$800.00
97290
Hair cotter pin, 5/16" - 3/8" x 1 5/8"
1
$0.47
28
80575
Wall switch, 120v white (not shown)
1
$77.00
40961
Wall switch, 120v ivory (not shown)
1
$77.00
11147
Wall switch, 240v white double push putton (not shown)
1
$77.00
38463E
Wall switch, 240v white rocker (not shown)
1
$77.00
