Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
13 90910 White base for 60" and 72" diag. screens 1 $109.00
90911 White base for 70", 84" diag. and 77" diag. screens 1 $117.00
90912 White base for 84", 96" diag., 100" diag. and 92" diag. screens 1 $124.00
90913 White base for 8', 120" diag. and 106" diag. screens 1 $129.00
90915 White base for 60" and 72" diag. screens with LVC 1 $116.00
90916 White base for 70", 84" diag. and 77" diag. screens with LVC 1 $120.00
90917 White base for 84", 96" diag., 100" diag. and 92" diag. screens with LVC 1 $127.00
89192 White base for 8', 120" diag. and 106" diag. screens with LVC 1 $132.00
14 89619 Pin end cap, white 1 $6.95
15 90483 Screw for end caps 6 $0.29
16 90920 White cover for 60" and 72" diag. screens 1 $105.00
90921 White cover for 70", 84" diag. and 77" diag. screens 1 $111.00
90922 White cover for 84", 96" diag., 100" diag. and 92" diag. screens 1 $119.00
90923 White cover for 8', 120" diag. and 106" diag. screens 1 $126.00
90925 White cover for 60" and 72" diag. screens with LVC 1 $107.00
90926 White cover for 70", 84" diag. and 77" diag. screens with LVC 1 $116.00
90927 White cover for 84", 96" diag., 100" diag. and 92" diag. screens with LVC 1 $120.00
89193 White cover for 8', 120" diag. and 106" diag. screens with LVC 1 $127.00
17 89571 Hanger bracket 2 $10.25
18 37312 Set screw for hanger brackets 4 $0.64
19 54520 Connector, cable 3/8" 1 $1.27
20 89618 Motor end cap, white 1 $6.95
89615 Motor end cap assy., white 120v for screens with LVC (includes #19) 1 $333.00
90933 Motor end cap assy., white 120v for screens with Wireless LVC/IR (includes #19) 1 $394.00
32095 Motor end cap assy., white 240v for screens with LVC (includes #19) 1 $333.00
32614 Motor end cap assy., white 240v for screens with Wireless LVC/IR (includes #19) 1 $394.00
21 97719 Strain relief 1 $0.44
22 89464 Screw for cover plate, white 1 $0.37
23 89617 Cover plate, motor end cap 1 $4.30
24 37739WHITE Wire cover for standard screens 1 $2.65
89572 LVC cover 1 $3.30
91651 LVC/IR cover 1 $3.30
25 77814 Screw for LVC and LVC/IR cover, black 2 $0.37
26 89576 Roller bracket, motor end (prior to 9/04/07) (not shown) 1 $12.70
36158 Roller bracket, motor end 1 $12.70
91795 Roller bracket assy., motor end for LVC and LVC/IR (prior to 9/04/07) (not shown) 1 $12.90
93519 Roller bracket assy., motor end for LVC and LVC/IR (not shown) 1 $12.90
27 35100 Motor and assy., 120v 1 $243.00
32707 Motor and assy., 240v 1 $243.00
28 97290 Hair cotter pin, 5/16" - 3/8" x 1 5/8" 1 $0.47
29 76286 Cord set with switch for Designer Cinema 1 $65.80
51521WHITE Cord set for built-in Infrared Remote Designer Contour screens, 120v (not shown) 1 $21.25
30 80575 Wall switch, 120v white (not shown) 1 $77.00
40961 Wall switch, 120v ivory (not shown) 1 $77.00
11147 Wall switch, 240v white double push putton (not shown) 1 $77.00
38463E Wall switch, 240v white rocker (not shown) 1 $77.00
