85 Executive Electrol E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
3 83383 Tape for pocket, black 2 $0.64
91876 Tape for pocket, black (not shown) 2 $0.64
4a Fabric only. See 4b for fabric and roller assembly.
79648 Fabric, Matte White 60" x 60" 1 $116.00
79649 Fabric, Matte White 70" x 70" 1 $142.00
79650 Fabric, Matte White 84" x 84" 1 $230.00
79643 Fabric, Matte White 6' x 8' 1 $294.00
79625 Fabric, Matte White 8 ' x 8' 1 $331.00
79627 Fabric, Matte White 7' x 9' 1 $343.00
46203 Fabric, Matte White 9' x 9' 1 $528.00
79631 Fabric, Matte White 8' x 10' 1 $395.00
46205 Fabric, Matte White 10' x 10' 1 $658.00
76957 Fabric, Matte White 9' x 12' 1 $748.00
96912 Fabric, Matte White 12' x 12' 1 $1,215.00
46134 Fabric, Matte White 10'6" x 14' 1 $1,288.00
46135 Fabric, Matte White 14' x 14' 1 $1,665.00
46136 Fabric, Matte White 12' x 16' 1 $1,568.00
46137 Fabric, Matte White 16' x 16' 1 $2,082.00
4b For complete fabric and roller assy., order as follows: (includes #1,2,3, and 4a)
71022 Fabric and roller assy., Matte White 60" x 60" 1 $524.00
71024 Fabric and roller assy., Matte White 70" x 70" 1 $594.00
71026 Fabric and roller assy., Matte White 84" x 84" 1 $696.00
71028 Fabric and roller assy., Matte White 6' x 8' 1 $696.00
71030 Fabric and roller assy., Matte White 8 ' x 8' 1 $739.00
71032 Fabric and roller assy., Matte White 7' x 9' 1 $784.00
71034 Fabric and roller assy., Matte White 9' x 9' 1 $786.00
71036 Fabric and roller assy., Matte White 8' x 10' 1 $1,007.00
71038 Fabric and roller assy., Matte White 10' x 10' 1 $961.00
71040 Fabric and roller assy., Matte White 9' x 12' 1 $1,105.00
71042 Fabric and roller assy., Matte White 12' x 12' 1 $2,112.00
71043 Fabric and roller assy., Matte White 10'6" x 14' 1 $1,888.00
71044 Fabric and roller assy., Matte White 14' x 14' 1 $2,716.00
71045 Fabric and roller assy., Matte White 12' x 16' 1 $2,656.00
71046 Fabric and roller assy., Matte White 16' x 16' 1 $3,275.00
5 83702 Screw for ironing board 5-7 $0.16
6 44735 Lock washer for ironing board 5-7 $0.45
7 97724 Ironing board bracket for 14' through 16' screens 5-7 $3.30
8 50877 Nut for ironing board 5-7 $0.90
9 83501 Screw for roller bracket 8 $0.60
10 44810 Screw for bumper bracket assy. 4 $0.42
11 80874 Nut for bumper bracket assy. 4 $0.32
12 83699 Ironing board for 14' wide screens 1 $101.00
83718 Ironing board for 16' wide screens 1 $107.00
13 44777 Screw for ironing board bracket 5-7 $0.16
14 44880 Screw for access door bracket and to attach hinge to case 2/brkt $0.27
15 46645 Hanging bar 4 $31.30
----- Screw for hanging bar (not shown) - No longer available 12 -----
16 87058 Screw for door bumper bracket 4 $0.27
17 46643 Door bumper bracket 2 $3.30
18 83010 Roller bracket assy., right 1 $16.55
83017 Bearing, flange 1 $50.00
