171
DL–0673 (Rev. 2) 07.21
© 2021 Legrand AV Inc.
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
38443 Fabric assy., HD Progressive 0.6 81.5" x 192" - 208" CS diag. 1 $1,521.00
38453 Fabric assy., HD Progressive 0.9 81.5" x 192" - 208" CS diag. 1 $1,521.00
39180 Fabric assy., HD Progressive 1.1 81.5" x 192" - 208" CS diag. 1 $1,521.00
20572 Fabric assy., HD Progressive 1.1 Perf 81.5" x 192" - 208" CS diag. 1 $1,949.00
24932 Fabric assy., HD Progressive 1.3 81.5" x 192" - 208" CS diag. 1 $1,521.00
38643 Fabric assy., HD Progressive ReView 0.9 81.5" x 192" - 208" CS diag. 1 $1,521.00
38636 Fabric assy., Da-Mat 81.5" x 192" - 208" CS diag. 1 $1,253.00
38638 Fabric assy., Da-Tex 81.5" x 192" - 208" CS diag. 1 $1,571.00
Video (4:3) Format
75136 Fabric assy., Da-Mat 36" x 48" - 60" diag. 1 $434.00
75137 Fabric assy., Da-Tex 36" x 48" - 60" diag. 1 $343.00
75141 Fabric assy., Da-Mat 43" x 57 1/2" - 72" diag. 1 $477.00
75142 Fabric assy., Da-Tex 43" x 57 1/2" - 72" diag. 1 $372.00
75146 Fabric assy., Da-Mat 50 1/2" x 67" - 84" diag. 1 $546.00
75147 Fabric assy., Da-Tex 50 1/2" x 67" - 84" diag. 1 $436.00
75151 Fabric assy., Da-Mat 57 1/2" x 77" - 96" diag. 1 $596.00
75152 Fabric assy., Da-Tex 57 1/2" x 77" - 96" diag. 1 $554.00
75156 Fabric assy., Da-Mat 60" x 80" - 100" diag. 1 $624.00
75157 Fabric assy., Da-Tex 60" x 80" - 100" diag. 1 $590.00
75161 Fabric assy., Da-Mat 72" x 96" - 120" diag. 1 $786.00
75162 Fabric assy., Da-Tex 72" x 96" - 120" diag. 1 $750.00
75164 Fabric assy., Da-Mat 90" x 120" - 150" diag. 1 $926.00
75165 Fabric assy., Da-Tex 90" x 120" - 150" diag. 1 $890.00
75167 Fabric assy., Da-Mat 108" x 144" - 180" diag. 1 $1,328.00
75168 Fabric assy., Da-Tex 108" x 144" - 180" diag. 1 $1,301.00
84164 Fabric assy., Da-Mat 120" x 160" - 200" diag. 1 $1,445.00
84165 Fabric assy., Da-Tex 120" x 160" - 200" diag. 1 $1,517.00
84169 Fabric assy., Da-Mat 144" x 192" - 240" diag. 1 $1,665.00
84170 Fabric assy., Da-Tex 144" x 192" - 240" diag. 1 $1,571.00
8 Hanger hardware for 80" and smaller viewing width screens (not shown)
98645 47" top hanger bracket 1 $19.05
97315 Bottom wall bracket and hardware 1 $30.70
Hanger hardware for over 80" to 96" viewing width screens (not shown)
98646 (2) 47" top and bottom hanger brackets 1 $35.80
97316 Hardware 1 $33.80
Hanger hardware for over 96" viewing width screens (not shown)
98647 (2) 47" top and (1) 47" bottom hanger brackets 1 $52.80
97317 Hardware 1 $47.70
87014 Carton - longest tube length + 5" Per foot $2.30
89645 Carton - longest tube length + 8" for 200" diag., 240" diag., 193" diag., 220" diag. and 166" diag. to 208" diag. Per foot $3.90
