50
DL–0644 (Rev. 5) 07.21
© 2021 Legrand AV Inc.
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
96986 Connector assy., 120v for SCB-200 screens (not shown) 1 $4.10
32613 Connector assy., 240v for SCB-200 screens (not shown) 1 $4.10
22 91861 PCB and base assy., 120v for SCB-100 screens (prior to 4/01/07) 1 $579.00
34324 PCB and base assy., 120v for SCB-100 screens 1 $579.00
91862 PCB and base assy., 240v for SCB-100 screens (prior to 4/01/07) 1 $579.00
32695 PCB and base assy., 240v for SCB-100 screens 1 $579.00
96995 PCB and base assy., 120v for SCB-200 screens (prior to 4/01/07) 1 $504.00
34325 PCB and base assy., 120v for SCB-200 screens 1 $1,000.00
32612 PCB and base assy., 240v for SCB-200 screens (prior to 4/01/07) 1 $504.00
32696 PCB and base assy., 240v for SCB-200 screens 1 $1,000.00
23 84479 Bracket assy., motor end (prior to 4/01/07) 1 $20.40
34159LGW Bracket, motor end (after 4/01/07 to 7/22/07) 1 $20.40
23102 Bracket, motor end 1 $20.40
24 37987KIT Motor assy., 120v for standard and SCB-100/200 screens with 3" rollers 1 $390.00
32259SKIT Motor assy., 120v Silent for standard and SCB-100/200 screens with 3" rollers 1 $487.00
38891KIT Motor assy., 120v for LVC and VPI screens with 3" rollers 1 $487.00
38891LSKIT Motor assy., 120v Silent for LVC and VPI screens with 3" rollers 1 $585.00
37989KIT Motor assy., 120v for standard and SCB-100/200 screens with 3.25" rollers 1 $390.00
32261SKIT
Motor assy., 120v Silent for standard and SCB-100/200 screens with 3.25" rollers up to and including 10' x
10'
1 $487.00
38890KIT Motor assy., 120v for LVC and VPI screens with 3.25" rollers 1 $487.00
38890LSKIT Motor assy., 120v Silent for LVC and VPI screens with 3.25" rollers up to and including 10' x 10' 1 $585.00
32688KIT Motor assy., 240v for standard and SCB-100/200 screens with 3" rollers 1 $390.00
32271SKIT Motor assy., 240v Silent for standard and SCB-100/200 screens with 3" rollers 1 $487.00
30833KIT Motor assy., 240v for LVC screens with 3" rollers before 4/12/2018 1 $800.00
12146KIT Motor assy., 240v for LVC screens with 3" rollers 4/12/2018 and after 1 $487.00
30833LSKIT Motor assy., 240v Silent for LVC screens with 3" rollers before 6/11/2018 1 $585.00
12278KIT Motor assy., 240v Silent for LVC screens with 3" rollers 6/11/2018 and after 1 $585.00
32692KIT Motor assy., 240v for standard and SCB-100/200 screens with 3.25" rollers 1 $390.00
32269SKIT
Motor assy., 240v Silent for standard and SCB-100/200 screens with 3.25" rollers up to and including 10' x
10'
1 $487.00
32645KIT Motor assy., 240v for LVC screens with 3.25" rollers before 4/12/2018 1 $800.00
32703RPL Motor assy., 240v for 12' x 12' LVC screens with 3.25" rollers before 4/12/2018 1 $1,000.00
12147KIT Motor assy., 240v for all LVC screens with 3.25" rollers 4/12/2018 and after 1 $487.00
32645LSKIT Motor assy., 240v Silent for LVC screens with 3.25" rollers up to and including 10' x 10' before 6/11/2018 1 $585.00
12279KIT Motor assy., 240v Silent for LVC screens with 3.25" rollers up to and including 10' x 10' 6/11/2018 and after 1 $585.00
94785 Drive wheel/rubber mount for screens purchased before 1/22/04 (not shown) 1 $60.00
25 97290 Hair cotter pin, 5/16" - 3/8" x 1 5/8" 1 $0.47
26 97319 Hangers and hardware for under 8' screens (not shown) 1 $15.75
97320 Hangers and hardware for 8' and over screens (not shown) 1 $23.15
38885 Built-in motor hardware kit (not shown) 1 $298.00
99607 ILT/LVC motor hardware kit (not shown) 1 $120.00
38885B Built-in motor hardware kit for case only (not shown) 1 $94.40
99607B ILT/LVC motor hardware kit for case only (not shown) 1 $94.40
80575 Wall switch, 120v white (not shown) 1 $77.00
40961 Wall switch, 120v ivory (not shown) 1 $77.00
11147 Wall switch, 240v white double push putton (not shown) 1 $77.00
38463E Wall switch, 240v white rocker (not shown) 1 $77.00
