Da-Lite 37989KIT Motor Drive Wheel Kit (120 VAC) - Manual (Page 96)

96 Tensioned Contour Electrol E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
92501 Fabric and roller assy., Da-Mat 69" x 92" - 120" diag. 1 $1,103.00
92511 Fabric and roller assy., Da-Mat 87" x 116" - 150" diag. 1 $1,493.00
82700 Fabric and roller assy., Da-Mat 108" x 144" - 180" diag. 1 $2,117.00
82703 Fabric and roller assy., Da-Mat 120" x 160" - 200" diag. 1 $2,524.00
6 46394 Flanged bearing 1 $0.53
7 37137 Roller bracket assy., pin end (prior to 7/16/07) (not shown) 1 $14.25
92382 Roller bracket assy., pin end for 10' x 10' and below screens (includes #6, 8 and 9) 1 $25.00
28354 Roller bracket assy., pin end for over 10' x 10' screens (includes #6, 8 and 9) (not shown) 1 $25.00
8 34137 Bolt for roller brackets 4 $0.72
9 23104 Hex nut for roller brackets 4 $0.32
10 88770 Hanger bracket for through 8' screens (not shown) 1 $25.00
92866 Hanger bracket for 9' and 10' screens 1 $47.00
95041 Hanger bracket for over 10' screens (not shown) 1 $78.00
11 12870 Screw for hanger bracket, White (for screens with standard white case) 2 $0.20
12871 Screw for hanger bracket, Black (for screens with black case) 2 $0.25
12a
White base for standard, VPI, and LVC screens. See 12b for current SCB-100/200 screens and LVC screens
prior to 7/01/06. If your screen has a black case, remove the "WHITE" suffix to order the black base.
HDTV (16:9) Format
89465WHITE White base for 92" diag. standard, LVC and 120v VPI screens 1 $274.00
89469WHITE White base for 106" diag. standard, LVC and 120v VPI screens 1 $290.00
94811WHITE White base for 110" diag. standard, LVC and 120v VPI screens 1 $294.00
89472WHITE White base for 119" diag. standard, LVC and 120v VPI screens 1 $305.00
89476WHITE White base for 133" diag. standard, LVC and 120v VPI screens 1 $322.00
89479WHITE White base for 159" diag. standard, LVC and 120v VPI screens 1 $339.00
83689WHITE White base for 184" diag. standard, LVC and 120v VPI screens 1 $351.00
Wide (16:10) Format
38289WHITE White base for 94" diag. standard, LVC and 120v VPI screens 1 $274.00
71939WHITE White base for 109" diag. standard, LVC and 120v VPI screens 1 $290.00
89471WHITE White base for 113" diag. standard, LVC and 120v VPI screens 1 $290.00
21951WHITE White base for 123" diag. standard, LVC and 120v VPI screens 1 $305.00
38210WHITE White base for 130" diag. standard, LVC and 120v VPI screens 1 $312.00
32859WHITE White base for 137" diag. standard, LVC and 120v VPI screens 1 $322.00
38017WHITE White base for 164" diag. standard, LVC and 120v VPI screens 1 $339.00
33230WHITE White base for 189" diag. standard, LVC and 120v VPI screens 1 $351.00
Video (4:3) Format
89313WHITE White base for 72" diag. standard, LVC and 120v VPI screens 1 $245.00
89324WHITE White base for 84" diag. standard, LVC and 120v VPI screens 1 $263.00
94740WHITE White base for 100" diag. standard, LVC and 120v VPI screens 1 $274.00
89468WHITE White base for 120" diag. standard, LVC and 120v VPI screens 1 $290.00
89475WHITE White base for 150" diag. standard, LVC and 120v VPI screens 1 $322.00
89480WHITE White base for 180" diag. standard, LVC and 120v VPI screens 1 $339.00
89481WHITE White base for 200" diag. standard, LVC and 120v VPI screens 1 $351.00
Order the following base for current SCB-100/200 screens and LVC screens prior to 7/01/06. If your screen
has a black case, remove the "WHITE" suffix to order the black base.
HDTV (16:9) Format
89329WHITE White base for 92" diag. SCB-100/200 and 240v VPI screens 1 $286.00
90486WHITE White base for 106" diag. SCB-100/200 and 240v VPI screens 1 $300.00
94813WHITE White base for 110" diag. SCB-100/200 and 240v VPI screens 1 $302.00
90489WHITE White base for 119" diag. SCB-100/200 and 240v VPI screens 1 $316.00
90493WHITE White base for 133" diag. SCB-100/200 and 240v VPI screens 1 $332.00
90496WHITE White base for 159" diag. SCB-100/200 and 240v VPI screens 1 $347.00
