Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
1
78103
Microswitch assy., 120v 15, 19 and 19L AND 230V 10M and 15M
1
$50.60
30562
Microswitch assy., 240v for Euro Da-Lift 15, 19 and 19L
1
$50.60
2
78102
Cover, junction box plain
1
$2.90
3
46430
Junction box
2
$6.95
4
54520
Connector, cable 3/8"
2
$1.27
5
50450
Receptacle, duplex-black
1
$19.95
6
78101
Cover, duplex-receptacle
1
$2.30
7
83704
Connector, EMT 1/2"
2
$1.50
8
82736
Motor, 120v for Da-Lift 15 (after April, 1998), Da-Lift 19 and 19L
1
$1,034.00
82738
Motor, 240v Da-Lift 15, 19 and 19L
1
$1,034.00
9
78096
Motor bracket for Da-Lift 15, 19 and 19L
1
$15.10
78174
Angles and bar for Da-Lift 15
2
$168.00
78175
Angles and bar for Da-Lift 19
2
$173.00
78176
Angles and bar for Da-Lift 19L
2
$174.00
11
80575
Wall switch, 120v white (not shown)
1
$77.00
40961
Wall switch, 120v ivory (not shown)
1
$77.00
11147
Wall switch, 240v white double push putton (not shown)
1
$77.00
38463E
Wall switch, 240v white rocker (not shown)
1
$77.00
